VDE Certification PVC Sheath Bare Copper Cable AC Power Cords for Small Appliance

B&T (Zhangzhou) Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：for General Purpose Internal Wiring of Appliance
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：PVC

Base Info

  • Model NO.：H03VVH2-F
  • Material Shape：Round Wire
  • Range of Application：Flame Retardant
  • Certification：ISO9001, RoHS, VDE, Reach
  • Brand：B&T
  • Rated Temperature：80 ºC
  • Rated Voltage：300V
  • According to：UL Subject758, UL1581, C22.2
  • Test：Passes UL VW-1 & CSA FT1 Vertical Flame Test
  • Performance：for General Purpose Internal Wiring of Appliance
  • Conductor：Stranded, Tinned or Bare Copper Conductor
  • Delivery Time：in 7-10days
  • Color：Could Be Customized Color
  • Products Certification：UL,cUL,RoHS, Reach
  • Factory Certificate：ISO9001:2008 Standard
  • Transport Package：610 Feet in Roll
  • Specification：18~30AWG 1~34 Conductors
  • Trademark：B&T
  • Origin：Xiamen, Fujian
  • HS Code：8544492100
  • Production Capacity：300, 000km

Description

No./mmDia.Nom. Thick.Nom.Dia.Nom. Thick.Nom.Dia.Ω/kmmm²mmmmmmmmmm H03VVH2-F20.528/0.150.920.5420.653.30×5.3039H03VVH2-F20.7524/0.21.130.512.150.653.50×5.7026
