Layer Stranded Direct Burial Gyty53 Fiber Cable
Hangzhou Softel Optic Co., Ltd.- Application：Fiber Optic Cable
- Conductor Material：Fiber
- Cover Material：PE
- Type：G652D
- Material Shape：Hollow Line
- Conductor Type：Stranded
Base Info
- Model NO.：GYTY53 Fiber Cable
- Wire Core Material：Steel
- Certification：CE, ISO
- Model：MHYV-xx
- Brand：Softel
- Apply for：Directly Burial
- Fiber Count：2-144cores
- Cable Type：Sm or Mm
- Fiber Type：G652D
- Material of Jacket：MDPE,HDPE
- Fiber Optic Cable Tube：Central Loose Tube
- Model Name：Fiber Optic Cable
- Model No.：GYTA53
- Delivery Time：10 Days
- MOQ：2 Drum
- Transport Package：4km Wooden Drum
- Trademark：SOFTEL
- Origin：China
- HS Code：85176229
- Production Capacity：1000km Per Month
Description
Fiber count2~36 38~72 74~84 86~96 98~108 110~120 122~132 134~144 CSM/Steel wire (mm) --/2.0 --/2.2 3.0/2.2 3.8/2.2 4.5/2.2 5.2/2.2 5.8/2.2 6.6/2.2 Element number 6 6 7 8 9 10 11 12 Max. cores in tube 6 12 12 12 12 12 12 12 Cable diameter (mm) 13.7 14.5 15.4 16.2 16.9 17.6 18.3 19.1 Weight (kg/km) 208 236 258 281 301 322 342 369 Tensile strength (N) Long term 1000 Short term 3000 Crush Resistance (N/100mm) Long term 1000 Short term 3000 Bending Radius (mm) Static ≥12.5×Cable diameter Dynamic ≥25× Cable diameter Operating Temperature (°C) -40 -- +60 Application Direct burial
