RG6 Coaxial 18AWG CPR Rg59 RG6 Rg11 Coaxial Cable China

Zhejiang Kuayue Cable Co., Ltd.
  • Application：Multimedia, DVD Player, Speaker, Monitor, Telephone, iPod, Microphone
  • Color：Black
  • Type：Coaxial
  • Species：VGA
  • Connector：RCA
  • Material Shape：Round Wire

Base Info

  • Model NO.：rg6 coaxial
  • Wire Core Material：Bare Copper Wire
  • Certification：RoHS, CE, ISO9001
  • Brand：Hanxin
  • Transport Package：100,200,305,500m
  • Specification：18awg
  • Trademark：hanli
  • Origin：Zhejiang
  • HS Code：8544200000
  • Production Capacity：3000000m,Month

Description

Impedance75±5OhmNominal capacitance53pF/mVelocity of propagation66%Insulation resistance>2000Mohm.KmInner conductor resistance13.5Ohm/KmOuter conductor resistance24.1Ohm/KmOperating temperature range-30°C-+70°CCable weight(approx.)116.4-140.4Kg/Km
AttenuationFrequency(MHz)Attenuation(dB/100m)Attenuation(dB/100ft)503.10.951004.21.282506.82.073007.52.293507.92.414008.52.594509.12.775009.52.955010.13.0860010.53.275012.13.6986013.24.02100014.34.36145018.65.672050237.01


3) DBS-direct broadcasting satellite
3, Packing
1) Packing Lengths:
100m/roll, 200m/roll, 305m/roll, 100yard/roll, 200yard/roll, 300yard/roll
Other lengths available according to client's request;
2) Inner packing: Wooden reel, plastic reel, and paper reel available.
3) Outer packing: Carton box, pull out box, pallet available.
(Other packing available according to client's request. )
Coaxial Cables:
1) RG series Coaxial Cable: Rg59, rg6, rg7, rg8, rg11, RG58, rg142, rg174, rg178, rg213, rg214, RG316, etc.
2) JIS series Coaxial Cable: 1.5C-2V, 2.5C-2V, 3C-2V, 3C-2VR, 4C-2V, 5C-2V, 7C-2V, 10C-2V, 3D-2V, 5D-2V, 8D-2V, 10D-2V, etc.
3) Vatc series Coaxial Cable: 17vatc, 19vatc, 21vatc, 25vatc, kx6a, kx8
4) TRUNK Cable: 412, 500, 540
5) LMR SERIES: LMR200, LMR400, LMR600
6) Combined Cable: RG59+2C
Electrical & Mechanical CharacteristicsImpedance75±5OhmNominal capacitance53pF/mVelocity of propagation66%Insulation resistance>2000Mohm.KmInner conductor resistance13.5Ohm/KmOuter conductor resistance24.1Ohm/KmOperating temperature range-30°C-+70°CCable weight(approx.)116.4-140.4Kg/Km


AttenuationFrequency(MHz)Attenuation(dB/100m)Attenuation(dB/100ft)503.10.951004.21.282506.82.073007.52.293507.92.414008.52.594509.12.775009.52.955010.13.0860010.53.275012.13.6986013.24.02100014.34.36145018.65.672050237.01
RG6 Coaxial 18AWG CPR Rg59 RG6 Rg11 Coaxial Cable ChinaRG6 Coaxial 18AWG CPR Rg59 RG6 Rg11 Coaxial Cable ChinaRG6 Coaxial 18AWG CPR Rg59 RG6 Rg11 Coaxial Cable China

Welcome to visit our factory and  get our samples.
  Your inquiry will be answered within 24 hours .Wishing to be your long- term partner ,please feel free to contact me ,we will do our best for you.

Choose us, won't make you disappointed:
1.6years manufactory experience
2.OEM/ODM available
3.Steady product quality
4.Strict quality control
5.Strictly conform to CE,ROHS,Iso9001
6.Quick delivery time(20ft,25days)
