Small Electrical Instrument PVC Insulation Supply Wire

B&T (Zhangzhou) Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Insulation Material：PVC
  • Material Shape：Round Wire
  • Range of Application：Flame Retardant

Base Info

  • Model NO.：H05VV-F-0003
  • Certification：ISO9001, UL, RoHS
  • Rated Temperature：80 ºC
  • Rated Voltage：12-14V
  • According to：UL Subject758, UL1581, C22.2
  • Test：Passes UL VW-1 & CSA FT1 Vertical Flame Test
  • Performance：for General Purpose Internal Wiring of Appliance
  • Conductor：Stranded, Tinned or Bare Copper Conductor
  • Capacity：300,000km Annual
  • Color：Could Be Customized Color
  • Delivery Time：7-15days
  • Package：Coil or Spool Packing
  • Transport Package：610feet in Roll
  • Specification：2pin 20 AWG 2 Conductors
  • Trademark：B&T
  • Origin：Xiamen, Fujian
  • HS Code：8544492100
  • Production Capacity：300, 000km

Description

Rated Temperature60ºC, 75ºC, 90ºC, 105ºC  InsulatedPVC insulation StandardMaximum Resistance at 20ºC
Ω/kmCross Section
mm²No./mmDia.
mmNom. Thick.
mmNom.Dia.
mmNom. Thick.
mmNom.Dia.
mmH03VVH2-F20.75 42/0.1471.10 0.54 2.17 0.63 3.55×5.6026.00 H05VV-F20.75 24/0.21.13 0.65 2.43 0.82 6.50 26.00 H05VV-F30.75 30/0.1771.11 0.62 2.35 1.07 7.25 26.00
