NFC Standard Almelec AAAC Conductor

YIFANG ELECTRIC GROUP INC.
  • Application：Power Station
  • Voltage：High Voltage Cable
  • Current：DC & AC
  • Insulation Material：Bare
  • Sheath Material：No
  • Material Shape：Round Wire

Base Info

  • Model NO.：AAAC
  • Wire Core Material：Aluminium Alloy
  • Certification：ISO, CCC
  • Model：AAAC
  • Brand：Yifang
  • Standard：NFC 34 215
  • Transport Package：Treated Wooden Drum
  • Specification：54.6 75.5 117 228 MM2
  • Trademark：YIFANG
  • Origin：China
  • HS Code：8544609000
  • Production Capacity：10000m Per Week

Description

Specifications ApplicationUsed as bare overhead conductor for primary and secondary distribution. Designed utilizing a high-strength aluminum alloy to achieve a high strength-to-weight ratio; affords better sag characteristics. Aluminum alloy gives AAAC higher resistance to corrosion than ACSRManufactured standardsNFC34125PackingIn drums



Detailed data

CodeCross-section Area
mm2		Number of wiresDiameter of wire
mm		Overall diameter of conductor
mm		Linear mass
kg/km		Rated tensile strength
KN
2524.272.10 6.30 66 7.87
3534.472.50 7.50 94 11.18
5554.673.15 9.45 149 17.75
9593.3192.50 12.50 254 30.32
153152.8193.20 16.00 417 49.66
210210.3372.69 18.83 573 68.35
228227.8372.80 19.60 621 74.04
248247.8372.92 20.44 676 80.54
297297.6373.20 22.40 811 96.72
323312.6373.28 22.96 853 101.60
366366.2373.55 31.95 999 119.02
446445.7613.05 27.45 1215 144.85
475475.4613.15 28.35 1296 154.51
570570.2613.45 31.05 1555 185.32
621620.9613.60 32.40 1693 201.79
926926.3913.60 32.40 2526 301.05
