H07rn8-F Rubber Class 5, Oil-Resistant Flame-Retardant Heavy 450/750V Submersion up to a Depth of 10m Submersible Pump Cable Power Control Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Underground
- Conductor Material：Copper
- Sheath Material：Rubber
- Insulation Material：Rubber
Base Info
- Model NO.：H07RN8-F
- Material Shape：Round Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, CE, UL, CCC, RoHS, VDE
- Brand：Feiya
- Color：Black Red Yellow, According to Voltage Level
- Whether It Is Environmentally Friendly：Yes
- Whether Quality Inspection：Provide Inspection Certificate
- Standard：Customized According to Specified National Standar
- OEM/ODM：Accepted
- Core：Single Core and Multicore
- Transport Package：Standard Export Packaging
- Specification：International General Specifications
- Trademark：Fengda
- Origin：Tianjin, China(Mainland)
- HS Code：8544492100
- Production Capacity：5000000km,Year
Description
APPLICATION
For installation in dry, damp or wet environments, in workshops with explosive atmospheres:
it can be immersed in fresh water up to 10m depth and it could be used as energy supply cable for submersed pumps.
Not suitable for underwater power transmission or installation in a waterway or where mechanical damage might occur and cause hazard. For connections liable to moderate mechanical stresses i.e. industrial or agricultural workshop apparatus, large boilers, heater plates, electric tools such as drills and disk saws, electric appliances, portable motors and generators on building sites; also for fixed installations along floors or shelving on temporary job sites, for connecting structural elements in lifting apparatus, machinery, etc. Suitable for applications up to 1kV for adequately protected fixed installations (i.e. inside pipes or equipment) as well as for rotor connections to lifting equipment motors.
CONSTRUCTION
Conductor
Class 5 flexible copper conductor
Insulation
Rubber
Sheath
Rubber
CHARACTERISTICS
Voltage Rating U/Uo
450/750V
Temperature Rating
Fixed: -40°C to +60°C
Flexed: -15°C to +60°C
Minimum Bending Radius
Fixed: 4 x overall diameter
Flexed: 6 x overall diameter
DIMENSIONS
| NO. OF | NOMINAL CROSS | CONDUCTOR | MINIMUM OVERALL | MAXIMUM OVERALL | NOMINAL |
| CORES | SECTIONAL AREA | DIAMETER | DIAMETER | DIAMETER | WEIGHT |
| mm2 | mm | mm | mm | kg/km | |
| 1 | 1.5 | 1.5 | 5.7 | 7.1 | 50 |
| 1 | 2.5 | 1.9 | 6.3 | 7.9 | 70 |
| 1 | 4 | 2.4 | 7.2 | 9 | 100 |
| 1 | 6 | 3 | 7.9 | 9.8 | 130 |
| 1 | 10 | 3.9 | 9.5 | 11.9 | 200 |
| 1 | 16 | 4.9 | 10.8 | 13.4 | 280 |
| 1 | 25 | 6.1 | 12.7 | 15.8 | 400 |
| 1 | 35 | 7.3 | 14.3 | 17.9 | 510 |
| 1 | 50 | 8.9 | 16.5 | 20.6 | 710 |
| 3 | 1.5 | 1.5 | 9.2 | 11.9 | 150 |
| 3 | 2.5 | 1.9 | 10.9 | 14 | 210 |
| 3 | 4 | 2.4 | 12.7 | 16.2 | 280 |
| 3 | 6 | 3 | 14.1 | 18 | 370 |
| 3 | 10 | 3.9 | 19.1 | 24.2 | 660 |
| 3 | 16 | 4.9 | 21.8 | 27.6 | 920 |
| 3 | 25 | 6.1 | 26.1 | 33 | 1360 |
| 3 | 35 | 7.3 | 29.3 | 37.1 | 1820 |
| 3 | 50 | 8.9 | 34.1 | 42.9 | 2500 |
| 4 | 1 | 1.2 | 9.2 | 11.9 | 150 |
| 4 | 1.5 | 1.5 | 10.2 | 13.1 | 190 |
| 4 | 2.5 | 1.9 | 12.1 | 15.5 | 260 |
| 4 | 4 | 2.4 | 14 | 17.9 | 350 |
| 4 | 6 | 3 | 15.7 | 20 | 460 |
| 4 | 10 | 3.9 | 20.9 | 26.5 | 830 |
| 4 | 16 | 4.9 | 23.8 | 30.1 | 1190 |
| 4 | 25 | 6.1 | 28.9 | 36.6 | 1720 |
| 4 | 35 | 7.3 | 32.5 | 41.1 | 2260 |
| 7 | 1.5 | 1.5 | 15 | 19 | 340 |
| 7 | 2.5 | 1.9 | 17.5 | 21.5 | 500 |
| 12 | 1.5 | 1.5 | 17.6 | 22.4 | 530 |
| 12 | 2.5 | 1.9 | 20.6 | 26.2 | 720 |
| 18 | 1.5 | 1.5 | 20.7 | 26.3 | 700 |
| 24 | 1.5 | 1.5 | 24.3 | 30.7 | 960 |
| 36 | 1.5 | 1.5 | 27.8 | 35.2 | 1360 |
