• Model NO.：PH30 & PH120 Cable
• Material Shape：Round Wire
• Range of Application：LSOH
• Certification：ISO9001, CCC, SGS
• Brand：Hongda
• Product Features：Outdoor and Underground Applications When Installe
• Transport Package：100m Per Roll, 150m, or 500m
• Specification：1.6mm2 to 500mm2
• Trademark：Hongda
• Origin：China
• HS Code：8544492100
• Production Capacity：40km,Day

ELECTRICAL DATA (AT20OC)Minimum
Bend RadiusMin.
Insulation
resistanceMax.Working
TemperatureTest voltage
(rms value)Max.
Operating
voltage
peak value MΩ/km ºCVV8×Diameter300-40ºC~+90ºC1000300/500TYPES AND MECHANICAL DATA

Types
sqmm

(mm2)

ConductorInsulationShielded1/
Drain Wire /
Shielded2Level of
twistingJacket
MatterialOD of
Jacket (mm)2×1.0BC Class 1,5RubberFiber Tape/AL-Foil TCFR-LSZH7.00±0.204×1.0BC Class 1,5RubberFiber Tape/AL-FoilTCFR-LSZH8.00±0.202×1.5BC Class 1,5RubberFiber Tape/AL-FoilTCFR-LSZH7.50±0.204×1.5BC Class 1,5RubberFiber Tape/AL-FoilTCFR-LSZH8.60±0.202×2.5BC Class 1,5RubberFiber Tape/AL-FoilTCFR-LSZH8.50±0.204×2.5BC Class 1,5RubberFiber Tape/AL-FoilTCFR-LSZH10.0±0.202×4.0BC Class 5RubberFiber Tape/AL-FoilTCFR-LSZH9.80±0.204×4.0BC Class 5RubberFiber Tape/AL-FoilTCFR-LSZH11.70±0.20         *NotesClass Types:Class1: Solid / Class 5: Flexible FR-LSZH:LSZH thermoplastic material Type LTS3 to BS 7656-6.1 Silicone Rubber:High performance silicone rubber EI2 to BS EN 50363-1TECHNICAL DATA

Types
sqmm

(mm2)

Max.Resistance
of Cond.at 20ºCCurrent Carrying
Capacity(Amperes)Nominal
Capacitance
(pF/m) Class 1,2Class 5Clipped In ConduitCoreScreen1.00 18.10 Ω/km19.50 Ω/km19171001701.50 12.10 Ω/km13.30 Ω/km24221101902.50   7.41 Ω/km  7.98 Ω/km33301302204.00   4.61 Ω/km  4.95 Ω/km4540160270       Order Informations:  Marking

HONGDA CABLE PH120 SR 114E Enhanced Cable N*NNmm2  XXX M

  Package500M/Wooden Spool, 1 Spool/Carton
*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!
Any needs or question, please contact me Mobile:+86-15838290725 , we will be more pleasure to service you.
We are looking forward to your inquiry and nice cooperation.
