• Model NO.：RG6
• Certification：CE, ISO, RoHS, UL
• Brand：Hongfeng
• HS Code：85442000
• Production Capacity：30, 000piece,Year

Basic Info.

Model NO. RG6 Certification CE, ISO, RoHS, UL Brand Hongfeng HS Code 85442000 Production Capacity 30, 000piece/Year

Product Description

Basic Info

Model NO.: RG6 Coaxial Cable
Wire Core Material: Bare Copper Wire
Certification: CE, ISO, RoHS, ETL
Model: RG6 Coaxial Cable
Brand: hongfeng
Place of Origin: Zhejiang, China (Mainland)
Center Conductor: Copper Clad Steel/Bare Copper
Dielectric: Foam PE/Solid PE
Shield: Bonded Al Foil/Common Al Foil
Braiding: Aluminum Wire
Jacket: PVC/PE/Lzsh
Jacket O.D: 6.9mm
Certifications: CE/ISO/ETL/ RoHS/UL /Reach
Trademark: Xingfa or OEM
Transport Package: 305m Wooden Spool
Specification: rg6 coaxial cable
Origin: Zhejiang, China (Mainland)
HS Code: 85442000


Product Description

1.Specifications:
1) [1.02mmCCS+4.57mmFoamed PE+A/P(bonded)+60%AL Braiding+6.91PVC ]X2
2) Customers' specifications are welcomed

2.Characteristics:
Impedance: 75+/-3 Ohm
Velocity of Propagation: 85%
Capacitance: 52 pF/m
Return Loss: 20dB min
Attenuation: [@60 F. (20 C) ] dB/100meters
5MHz: 1.90dB 500MHz: 15.09dB
55MHz: 5.25dB 600MHz: 16.73dB
83MHz: 6.40dB 750MHz: 18.54dB
187MHz: 9.35dB 1000MHz: 21.49dB
211MHz: 10.00dB 1450MHZ: 26.16dB
250MHz: 10.82dB 1800MHZ: 27.73dB
350MHz: 12.63dB 2100MHZ: 31.15dB
400MHz: 13.61dB 2250MHZ: 34.03dB


3.Packing:
1) Packing Lengths: 100m/roll, 200m/roll, 305m/roll......
Other lengths available according to client's request;
2)Inner packing:Wooden reel, plastic reel...
3)Outer packing:Carton box, pull box,pallet...
4)Other packing available according to client's request.


Coaxial Cable RG6/U, high performance follow Belden Standards.
Inner conductor: 1.02mm (18AWG) BC or CCS
Dielectric: Physical Gas Injected Foame PE 4.57mm
Shealth 1st: Bonded/Unbonded Aluminum Foil or Al/Pet/Al
Shealth 2nd: Braid, Al/BC/TC wire 0.12/0.15mm/0.16mm coverage: 40%-95%
Jacket: 6.91mm PVC or PE

Characteristic same as Belden and Commscope Standards.

Inner Packing: Wooden/plastic drum/Cardboard Drum, Coil.
Outer packing: Carton box, Pull out box.
