Control PUR-Jz Screened Cable Highly Resistant Against Wear and Tear 1.5mm2 2.5mm2

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：PUR
  • Insulation Material：PVC
  • Material Shape：Round Wire

Base Info

  • Model NO.：PUR-JZ Cable
  • Range of Application：Electrical Facilities
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemPUR-JZ CableConductorClass 5 flexible plain copper wiresInsulationPVC (Polyvinyl Chloride)ScreenTCWB (Tinned Copper Wire Braid)Outer sheathPUR (Polyurethane)Core NumberMulticores (As client's requirement)Temperature rangeFixed: -40ºC to +80ºC

Installation: -5ºC to +80ºCRated voltageUo/U 0.6/1 kVColorOptionalApplicationThese Screened Polyurethane cables are highly resistant against wear and tear. The oil and coolant resistance allows application in industrial environments, machine building, engineering or steel works. This cable is suitable for medium mechanical stress without tension load and forced guiding.
