• Model NO.：solar cable-Dayuan-1
• Material Shape：Round Wire
• Range of Application：Solar Power Generation System
• Certification：ISO9001, CE, CCC, TUV
• Brand：Dayuan
• Transport Package：Use The Drum, We Can Make as Customer Requirement
• Specification：we can make as customer requirement
• Trademark：DAYUAN
• Origin：China
• HS Code：85444929
• Production Capacity：10000 Meters,Day

MODEL PV1-FConductorTinned copper wire,class 5 (as per IEC 60228)InsulationNo Halogen PO insulationSheathNo Halogen PO sheathrated voltageAC  0.6/1KV DC  1.8KVTemperature range-40°C~+90°C,dry/ humidityMax.working temperature of conductor 120°CDuring short circuit 200°CStandardEN 2PFG 1169    type    Cross Sectional Area(mm2)Conductor structure( Strand /mm)diameter(mm)insulation thickness(mm)sheat thickness(mm)cable diameter(mm)DC resistance at 20°C(Ω/km) PV1-F      1.5     48/0.2    1.6    1.0    0.8    5.2      12.2 PV1-F      2.5     77/0.2    2.0     1.0    0.8    5.6     7.56 PV1-F       4     56/0.3    2.6    1.0    0.9    6.4      4.7 PV1-F       6     84/0.3    3.2    1.0    0.9    7.0     3.11 PV1-F      10    77/0.41    4.4    1.0    0.9    8.2     1.84 PV1-F      16   119/0.41    5.5    1.0    1.1    9.7     1.16 PV1-F      25   189/0.41    6.5    1.2    1.2   11.3    0.734 PV1-F      35   244/0.41    7.5    1.2    1.2   12.3    0.529
Company Information:

Luoyang Da Yuan Cable Factory Co., Ltd.is a professional leading manufacturer in the field of wires and cables, was established in 2006 of China. We have been specialized in producing wires and cables for several years which can be applied in many areas, our main products are power cable, solar cable, and overhead line cable like ACSR, AAC, ABC cable, control cable, transformer, and aluminum wire rod. We have advanced automatic production lines. Besides, we can provide the raw material of aluminum cable as well, thus our price is very competitive and reasonable.

Contact us:

Max Shang (Sales Manager)
Luoyang Da Yuan Cable Factory Co., Ltd.
Tel: +86-0379-69991591
Mobile: +86-13803889574
