Engineered Wooden Flooring Electrical Warm Feet System with Thermostats

Wuhu Jiahong New Material Co., Ltd.
  • Cable Construction：Single Conductor
  • Rated Voltage：220V
  • Output：18.5W,M
  • Heating Element Size：16.2m to 170.5m
  • Bending Radius：38mm
  • Cable Diameter：6.0-6.5mm

Base Info

  • Model NO.：TXLP 1
  • Conductor Insulation：XLPE
  • Outer Insulation：PVC
  • Max. Ambient Temp：85ºF(30ºC)
  • Min. Installation Temp：40ºF(5ºC)
  • Transport Package：Innner Carton Master Carton
  • Trademark：jiahong
  • Origin：Anhui Wuhu
  • Production Capacity：17000PCS Per Day

Description

Ohms

Catalog Number

TXLP/1 300

300

18.5

220

16.2

161.3

TXLP/1 400

400

18.5

220

21.6

121.0

TXLP/1 500

500

18.5

220

27.0

96.8

TXLP/1 600

600

18.5

220

32.3

80.7

TXLP/1 700

700

18.5

220

37.7

69.1

TXLP/1 850

850

18.5

220

45.9

56.9

TXLP/1 1000

1000

18.5

220

53.9

48.4

TXLP/1 1200

1200

18.5

220

65.0

40.3

TXLP/1 1400

1400

18.5

220

75.4

34.6

TXLP/1 1600

1600

18.5

220

86.5

30.3

TXLP/1 1760

1760

18.5

220

95.0

27.5

TXLP/1 2000

2000

18.5

220

108.1

24.2

TXLP/1 2200

2200

18.5

220

118.9

22.0

TXLP/1 2400

2400

18.5

220

129.9

20.2

TXLP/1 2600

2600

18.5

220

140.5

18.6

TXLP/1 2800

2800

18.5

220

151.4

17.3

TXLP/1 3150

3150

18.5

220

170.5

15.4


Company Information
1.About Us

WuHu Jiahong New Material Co. Ltd is the largest heating cable manufacturer in Asia-pacific. We are always dedicated to research, develop and produce both constant wattage and self-regulating heating cables since 1993. Till now, Jiahong has obtained more than 30 national patents. We are one of the few members of China self-regulating heating cable national standard GB/T 19835-2005.


Most of WuHu Jiahong products passed UL, CSA, ETL, TUV, CE, ATEX etc. We export to many regions, especially North America, Europe, Australia and Asia. High quality combines with professional services earned us a good reputation.

Engineered Wooden Flooring Electrical Warm Feet System with Thermostats


Our Services

We help our customer develop heating cable, floor heating, snow melting for their application and OEM offered.
Quality control
Engineered Wooden Flooring Electrical Warm Feet System with Thermostats
3. Company Certificates
Engineered Wooden Flooring Electrical Warm Feet System with Thermostats


The warm up time of an electric underfloor heating system will be dictated by the insulation used beneath it and the output of the system. In general, the better insulated the sub-floor the faster the system will warm up, with Underfloor Insulation boards?facilitating a very speedy warm up time of as little as 15 minutes, and un-insulated concrete floors causing the slowest warm up time. Using a?200W system?beneath ceramic/stone tiles provides a faster warm up time than 150W system.



2. Can I turn my heating on the day it is fitted?

If you have installed your heating beneath tile adhesive, levelling compound or a screed you must allow this to dry out before turning on your system for the first time. If the system is turned on too early it will force the moisture out of the covering which may lead it to crack. We would recommend speaking to the manufacturer of your flexible tile adhesive, grout or screed to confirm the drying time required.



3. Does each room require its own thermostat?

We would recommend that each room has its own heating system controlled by its own thermostat. This will allow for simpler and more accurate temperature control of each room and will avoid heating rooms which do not require it.
