Nyy H07z-R H07rnf Industrial Flexible Cable PVC Insulation PVC Outer Sheath Wire Cable

Tianjin Feiya Electric Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Class 5 Flexible Copper Conductor
  • Application：Heating, Underground
  • Conductor Material：Copper
  • Sheath Material：Pcp (Polychloroprene)
  • Insulation Material：Epr (Ethylene Propylene Rubber)

Base Info

  • Model NO.：H07RNF
  • Material Shape：Round Wire
  • Range of Application：Heavy Equipment, Machine Tools, Agricultural etc.
  • Certification：ISO9001, CE, CCC
  • Brand：Fengda
  • Color：Customized
  • OEM / ODM：Available
  • Whether Quality Inspection：Provide Inspection Certificate
  • Whether It Is Environmentally Friendly：Yes
  • Standard：Customized Based on Specified National Standard
  • Core：Single Core and Multicore
  • Transport Package：Drum , Roll
  • Specification：International General Specifications
  • Trademark：FengDa
  • Origin：China
  • HS Code：854449210
  • Production Capacity：5000000 Km , Year

Description

Introduction1Can be customized according to requirements.2Independent brand recruitment agency.3High quality, ISO 9001, CCC, CE, RoHS certified.4ODM&OEM is available.Nyy H07z-R H07rnf Industrial Flexible Cable PVC Insulation PVC Outer Sheath Wire Cable
Flexible Rubber Insulated Cable

Application:
H07RN-F flexible rubber cable is a heavy-duty rubber sheathed cable for use on heavy equipment, such as machine tools and agricultural machinery, cabel h07rn-f is exposed to high stress in dry and damp rooms as well as outdoors and in damp industrial environments. Constant, operational movements, the use of these cables in moving cable carriers, respectively on motor drum guides or a stress of more than 15 N/mm² is not permitted.

Standard:
EN 50525-2-21, EN 60228
Flame Retardant according toIEC/EN60332-1-2

Conductor: Class 5 flexible copper conductor
Insulation: EPR (Ethylene Propylene Rubber)
Sheath: PCP (Polychloroprene)
Voltage Rating (Uo/U): 450/750V

Temperature Rating :
Fixed: -30°C to +60°C
Fixed protected installations: +85°C
Flexed: -15°C to +60°C

Minimum Bending Radius:
Fixed: 4 x overall diameter
Flexed: 6 x overall diameter

H07RN-F Single Core Type 450/750V EPR/PCP Trailing Rubber Cable
Core and Size
(mm2)		Stranding
(Number of Strand /
 Strand Diameter)		Thickness of Sheath
(mm)		Nominal Overall Diameter
(mm)		Approx Weight
(kg/km)
1x1.530/0.250.8649
1x 2.550/0.250.96.663
1x456/0.3017.692
1x684/0.3018.3115
1x1080/0.401.210.7189
1x16126/0.401.212260
1x25196/0.401.414.1369
1x35276/0.401.415.8500
1x50396/0.401.618.3689
1x70360/0.501.620.7918
1x95475/0.501.823.41202
1x120608/0.501.825.61489
1x150756/0.50228.31824
1x185925/0.502.2312202
1x2401221/0.502.434.52847
1x3001525/0.502.637.73495
1x4002013/0.502.837.73495
1x5001769/0.60337.73495
1x6302257/0.60337.73495

H07RN-F 2 Core Type 450/750V EPR/PCP Trailing Rubber Cable
Core and Size
(mm2)		Stranding
(Number of Strand /
 Strand Diameter)		Thickness of Sheath
(mm)		Nominal Overall Diameter
(mm)		Approx Weight
(kg/km)
2 X 1.032/0.200.88.498
2 X 1.530/0.500.89.4116
2 X 2.550/0.250.911164
2 X 4.056/0.30112.8232
2 X 6.084/0.30114.2297
2 X 10.080/0.401.220.4573
2 X 16.0126/0.401.223774
2 X 25.0196/0.401.427.41110
2 X 35.0276/0.401.430.81474

H07RN-F 3 Core Type 450/750V EPR/PCP Trailing Rubber Cable
Core and Size
(mm2)		Stranding
(Number of Strand /
 Strand Diameter)		Thickness of Sheath
(mm)		Nominal Overall Diameter
(mm)		Approx Weight
(kg/km)
3 X 1.032/0.200.89108
3 X 1.530/0.500.810.3141
3 X 2.550/0.250.911.8200
3 X 4.056/0.30113.7285
3 X 6.084/0.30115.2371
3 X 10.080/0.401.221.9712
3 X 16.0126/0.401.224.7971
3 X 25.0196/0.401.429.41394

H07RN-F 4 Core Type 450/750V EPR/PCP Trailing Rubber Cable
Core and Size
(mm2)		Stranding
(Number of Strand /
 Strand Diameter)		Thickness of Sheath
(mm)		Nominal Overall Diameter
(mm)		Approx Weight
(kg/km)
4 X 1.032/0.200.810134
4 X 1.530/0.250.811.2174
4 X 2.550/0.250.912.6249
4 X 4.056/0.30115.1361
4 X 6.084/0.30116.9480
4 X 10.080/0.401.224890
4 X 16.0126/0.401.2271225
4 X 25.0196/0.401.432.61792
4 X 35.0276/0.41.436.52380
4 X 50.0396/0.41.6423635
4 X 70.0360/0.51.6494830
4 X 95.0475/0.51.8556320

H07RN-F 5 Core Type 450/750V EPR/PCP Trailing Rubber Cable
Core and Size
(mm2)		Stranding
(Number of Strand /
 Strand Diameter)		Thickness of Sheath
(mm)		Nominal Overall Diameter
(mm)		Approx Weight
(kg/km)
5 X 1.032/0.200.811170
5 X 1.530/0.500.812.3218
5 X 2.550/0.250.914.5309
5 X 4.056/0.30116.9450
5 X 6.084/0.30118.8595
5 X 10.080/0.401.226.51100
5 X 16.0126/0.401.2301528
5 X 25.0196/0.401.4362200
5 X 35.0276/0.401.4402925

H07RN-F Multicore Type 450/750V EPR/PCP Trailing Rubber Cable
Core and Size
(mm2)		Stranding
(Number of Strand /
 Strand Diameter)		Thickness of Sheath
(mm)		Nominal Overall Diameter
(mm)		Approx Weight
(kg/km)
7 X 1.530/0.500.814.6295
7 X 2.550/0.250.916.6410
12 X 1.530/0.500.818.9500
12 X 2.550/0.250.922720
19 X 1.530/0.500.822.5715
19 X 2.550/0.250.9261030
24 X 1.530/0.500.825900
24 X 2.550/0.250.9291350
27 X 1.530/0.500.8291100
27 X 2.550/0.250.9331521
37 X 1.530/0.500.829.81300
37 X 2.550/0.250.9361900
