T type Thermocouple Wire Copper constantan wire AWG 24 0.51mm for industrial temperature measuring
Shanghai Tankii Alloy Material Co., Ltd.- Type：Bare
- Conductor Type：Solid
- Application：Heating
- Conductor Material：Cu-CuNi
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Model NO.：T
- Material Shape：Round Wire
- Range of Application：Temperature Measurement
- Certification：ISO9001, CE, RoHS
- Brand：Tankii
- Dia：0.3,0.5,0.8,1.0,1.2,1.6,2.0,2.5,3.2mmm
- Surface：Bright, oxidized
- Grade：I,II,III
- Tensile strength：≥196
- Item：Type T Thermocouple Wire Copper constantan wire fo
- shape：round wire, flat wire
- wire status：soft, bright , annealing
- Leading time：about 5 days
- Brand name：Tankii Alloy
- MTC：Yes
- Transport Package：100m,Coil 500m,Coil
- Specification：0.3,0.5,0.8,1.0,1.2,1.6,2.0,2.5,3.2mm
- Trademark：TANKII
- Origin：Shanghai
- HS Code：7505220000
- Production Capacity：50000 Tons,Year
Description
Chemical CompositionConductor Name Polarity Code Nominal Chemical Composition /% Ni Cu
Copper
Positive
TP
--
100
Copper-Nickel
Negative
TN
45
55
Diameter/mm
Long time Working temperature /ºC
Short period Working temperature /ºC
0.2, 0.3150
200
0.5, 0.8200
250
1.0, 1.2250
300
1.6, 2.0
300
350
Copper
Positive
TP
--
100
Copper-Nickel
Negative
TN
45
55
Diameter/mm
Long time Working temperature /ºC
Short period Working temperature /ºC
0.2, 0.3
200
0.5, 0.8
250
1.0, 1.2
300
1.6, 2.0
300
350
