Flexible H07zz-F LSZH Cable CE Certified Power Cable

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Industrial Cable
  • Conductor Material：Copper
  • Sheath Material：LSZH
  • Insulation Material：LSZH

Base Info

  • Model NO.：H07ZZ-F
  • Material Shape：Round Wire
  • Range of Application：LSOH
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemH07ZZ-FConductorClass 5 flexible copper conductorInsulationLSZH (Low Smoke Zero Halogen) cross-linked compoundOuter SheathLSZH (Low Smoke Zero Halogen) cross-linked compoundRated Voltage 450/750VMinimum Bending RadiusFixed: 4 x overall diameter
Flexed: 6 x overall diameterTemperature RangeFixed: -20°C to +90°C
Flexed: -5°C to +50°CColorOptionalApplicationFor installation where fire, smoke emission and toxic fumes create a potential threat to life and equipment. Examples of use include supplying mobile power units, UPS installations, stage lighting and audio visual equipment. This cable will withstand medium mechanical stresses and is suitable for both installation indoors and outdoors
