RG6/U Copper Coaxial Cable

Hangzhou Spring Electronics Co., Ltd.
  • Application：Local Communication Cable, Coaxial Cable
  • Conductor Material：BC,CCS,CCA,TC,CU,CCAG
  • Cover Material：PVC
  • Type：RG6 Cable
  • Material Shape：Round Wire
  • Conductor Type：Stranded

Base Info

  • Model NO.：rg6
  • Wire Core Material：Bare Copper Wire
  • Certification：CE, ISO, RoHS
  • Brand：OEM
  • Cable Conductor：1.02mm
  • Transport Package：Roll,Wooden Spool,Plastic Reel,Gift Box,Pully Box
  • Trademark：FUU
  • Origin：Made in China
  • HS Code：8544200000
  • Production Capacity：3000km,Month

Description

Inner ConductorCuConductor Diameter1 x 1,02 mmInsulationFPEInsulation Diameter4,57 mmScreen TapeCu-Pes 100%BraidBraid with Copper WiresOuter SheathPVCSheath Diameter6,8 mmColour of SheathBlack - Orange



TECHNOLOGY DATA
Characteristic Impedance75±3Ohm
Capacitance52±1pF/m
Velocity>82%
Conductor & Dielectric To stick (kgt/m  1m/min)2.55kgf (10.2kgf/m)
Insulation resistance1000MOHM(20ºC)
Frequence (at 20ºC)Max.Attenuation
5MHz1.90dB/100m
55MHz5.30dB/100m
211MHz10.0dB/100m
270MHz11.0dB/100m
300MHz11.60dB/100m
330MHz12.30dB/100m
400MHz13.60dB/100m
450MHz14.40dB/100m
550MHz16.20dB/100m
750MHz19.00dB/100m
870MHz20.60dB/100m
1000MHz21.49dB/100m
