- Model NO.:TW
- Certification:ISO, CCC
- Model:Tw
- Brand:Boan
- Rated Voltage:450,750 V
- Size:0.5-2.5 Mm2
- Class of Conductor:B
- Number of Cores:1
- Transport Package:Heated Steel-Wooden Drum,Steel Drum
- Specification:SGS
- Trademark:DingAn or OEM
- Origin:Jiangsu Yixing, China
- HS Code:8544492100
- Production Capacity:22000 Km
Size | Section | Conductor Structure | Insulation Thickness | Outer Diameter | Weight |
AWG or MCM | mm2 | No. x mm | mm | mm | kg/km |
20 | 0,52 | 1 x 0.813 | 0,76 | 2,33 | 9,81 |
18 | 0,82 | 1 x 1,02 | 0,76 | 2,54 | 13,16 |
16 | 1,31 | 1 x 1,29 | 0,76 | 2,81 | 18,10 |
14 | 2,08 | 1 x 1,63 | 0,76 | 3,15 | 26,10 |
12 | 3,31 | 1 x 2,05 | 0,76 | 3,57 | 38,30 |
10 | 5,26 | 1 x 2,59 | 0,76 | 4,11 | 57,40 |
8 | 8,34 | 1 x 3,26 | 1,14 | 5,54 | 95,20 |
14 | 2,08 | 7 x 0,62 | 0,76 | 3,38 | 27,80 |
12 | 3,31 | 7 x 0,78 | 0,76 | 3,86 | 40,10 |
10 | 5,26 | 7 x 0,98 | 0,76 | 4,46 | 59,90 |
8 | 8,37 | 7 x 1,23 | 1,14 | 5,97 | 105,20 |
6 | 13,30 | 7 x 1,55 | 1,52 | 7,69 | 170,40 |
4 | 21,15 | 7 x 1,96 | 1,52 | 8,92 | 255,50 |
2 | 33,62 | 7 x 2,47 | 1,52 | 10,45 | 388,90 |
1 | 42,36 | 7 x 2,78 | 2,03 | 12,40 | 482,90 |
1/0 | 53,49 | 19 x 1,89 | 2,03 | 13,51 | 621,00 |
2/0 | 67,43 | 19 x 2,12 | 2,03 | 14,66 | 778,00 |
3/0 | 85,01 | 19 x 2,39 | 2,03 | 16,01 | 934,00 |
4/0 | 107,20 | 19 x 2,68 | 2,03 | 17,46 | 1159,00 |
250 | 127,00 | 37 x 2,09 | 2,41 | 19,45 | 1368,00 |
300 | 152,00 | 37 x 2,29 | 2,41 | 20,85 | 1623,00 |
350 | 177,00 | 37 x 2,47 | 2,41 | 22,11 | 1876,00 |
400 | 203,00 | 37 x 2,64 | 2,41 | 23,30 | 2128,00 |
500 | 253,00 | 37 x 2,95 | 2,41 | 25,47 | 2631,00 |
600 | 304,00 | 37 x 3,23 | 2,79 | 28,19 | 3174,00 |
650 | 329,00 | 37 x 3,37 | 2,79 | 29,17 | 3345,00 |
700 | 355,00 | 37 x 3,49 | 2,79 | 30,01 | 3609,00 |
