Overhead Conductor AAC AAAC ACSR Bare Conductors

Luoyang Sanwu Cable Co., Ltd.
  • Type：Bare
  • Conductor Type：Stranded
  • Application：Overhead
  • Conductor Material：Aluminum
  • Sheath Material：Bare
  • Insulation Material：Bare

Base Info

  • Model NO.：acsr conductor
  • Material Shape：Round Wire
  • Range of Application：Overhead
  • Certification：ISO9001, CE, CCC
  • Brand：Da Yuan
  • Color：Silver
  • Structure：Circular
  • Supplier：Manufacturer
  • Voltage：0.6,1kv,11kv,15kv,25kv
  • Standard：IEC, ASTM, BS
  • Export：Worldwide
  • Transport Package：Woodern Drum
  • Specification：ACSR conductor
  • Trademark：Da Yuan
  • Origin：China
  • HS Code：76149000
  • Production Capacity：5000km,Day

Description

Basic Info.

Model NO. acsr conductor Material Shape Round Wire Range of Application Overhead Certification ISO9001, CE, CCC Brand Da Yuan Color Silver Structure Circular Supplier Manufacturer Voltage 0.6/1kv,11kv,15kv,25kv Standard IEC, ASTM, BS Export Worldwide Transport Package Woodern Drum Specification ACSR conductor Trademark Da Yuan Origin China HS Code 76149000 Production Capacity 5000km/Day

Product Description

Applications  Used as bare overhead transmission cable and as primary and secondary distribution cable. ACSR offers optimal strength for line design. Variable steel core stranding enables desired strength to be achieved without sacrificing ampacity.

Specifications
ACSR bare conductor meets or exceeds the following ASTM specifications:
B-230 Aluminum Wire, 1350-H19 for Electrical Purposes
B-231 Aluminum Conductors, Concentric-Lay-Stranded
B-232 Aluminum Conductors, Concentric-Lay-Stranded, Coated Steel Reinforced (ACSR)
B-341 Aluminum-Coated Steel Core Wire for Aluminum Conductors, Steel Reinforced (ACSR/AZ)
B-502 Aluminum-Coated Steel Core Wire for Aluminum Conductors, Steel Reinforced (ACSR/AW)
B-498 Zinc-Coated Steel Core Wire for Aluminum Conductors, Steel Reinforced (ACSR/AZ)
B-500 Zinc Coated and Aluminum Coated Stranded Steel Core for Aluminum Conductors, Steel Reinforced (ACSR)

Material Standard:
1) The hard aluminum conductor used for AAC and ACSR conforms to the standard GB/T 17048-1997 (equivalent to IEC 60889:1987)
2) The zinc coated steel wire used for ACSR confirms to IEC 60888:1987
3) Production can be arranged according to customers' requirement such as material standard etc.
4) We can also produce products according to the Standard of BS215, ASTM B232, and DIN48204.
