Cable & Wire

Cheap Yarn PP Filler for Cable

Jiangxi Longtai New Material Co., Ltd.
  • Application:Construction, Overhead, Underground, Industrial, Power Station, Telecommunication, Computer, Car
  • Voltage:Low and Medium Voltage Cable
  • Current:AC Cable
  • Insulation Material:PVC
  • Sheath Material:PVC
  • Material Shape:Flat Wire

Base Info

  • Model NO.:1---20mm
  • Wire Core Material:Steel
  • Certification:ISO
  • Model:AGRP
  • Brand:Anshi
  • Size:0.8mm---30mm, 2000d----500kd
  • Linear Density:2kd-50kd
  • Breaking Strength:0.6--2.6g,D
  • Breaking Elongation:<20%
  • Hot Shrinkage Rate:4-6%
  • Color:Raw White, Black, Yellow
  • Twist:Z
  • Weight:5-20kg,Roll
  • Package:20-50kg,Bag
  • Use:Cable Filing
  • Transport Package:2.5---40kg,Roll
  • Specification:1---10mm
  • Trademark:LONGTAI
  • Origin:China Jiangxi
  • HS Code:54024800
  • Production Capacity:5000t,Year

Description


100% pp , pp filler  SpecificatiomsItemUnitstandardRemark  FinenessDspecification±8%3000D-300000D  Breakingg/d>2  tenacity  Tensibility%<20  shrinkage%<6120*30min  in hot air  AppearanceNatural  Color   or   White,color  obvious  stations



In a wide range of denier from 3000D to 300KD,Widely used in wire and cable.These are sold in shrink-wrapped coreless rolls,rolled on  paper cores and capable of working with continuing throughout their length.

                                            pp+caco3 wire cable pp filler  SpecificatiomsItemUnitstandardRemark  pp filler  FinenessDspecification±8%3000D-300000D  pp filler  Breakingg/d>0.3,>1g/d  tenacity  Tensibility%<20  shrinkage%<10120*30min  in hot air  AppearanceNatural  Color   or   White,No  obvious  stations


3.high tenacity polyester yarn and polyester thread


polyester sewing thread Spec.sewing thread   weight
(g/spool)
sewing thread  Length
(Y/spool)

840D/3
(0#)
 90 300----5000
630D/3
(5#)
 90 380----80000
500D/3
(10#)
 90 550---9000
 250D/4
(20#)
 90 800-----12000
 250D/3
(30#)
 90 1100---20000
 250D/2
(40#)
 90 1600----25000
 150D/3
(60#)
 90 1600------30000
 120D/3
(80#)
 90 2100-----300000


4. aramid yarn:200D,400D,1000D,1500D,3000D
   kelvar aramid yarn
aramid yarn is ahigh performance material,it comnines the characteristics of high strength and light weight. under the condition of equal weight,it is 5 times the strength of steel wire,2.5 times fiberglass.
