Parallel Aerial Bunched Cable (1KV 4X50)
Luoyang Sanwu Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead
- Conductor Material：Aluminum
- Sheath Material：Non
- Insulation Material：XLPE
Base Info
- Model NO.：ABC-Dayuan-031
- Material Shape：Round Wire
- Range of Application：Overhead Transmision
- Certification：ISO9001, CE, CCC
- Brand：Dayuan
- Quality Check：All Products Checked by Experienced QC
- Trail Order：Welcome
- OEM Service：Welcome
- Delivery Date：15days~35days After Order Confirmed
- Other：High Voltage
- Conductor Shape：Circular Core or Compact Core
- Cross Section Area：1.5-800 mm2
- Standard：IEC502, BS7870-5, GB12527-91
- Key Word：Triplex Cable
- Transport Package：Use The Drum, We Can Make as Customer Requirement
- Specification：IEC, ASTM, ICEA, BS, DIN
- Trademark：Luoyang Dayuan
- Origin：Luoyang, China
- HS Code：85444929
- Production Capacity：100000m,Day
Description
codeRated Voltage Type ABC
AWG or kcmilStructure Neutral Wire (ACSR) Phase Wire Cable Cable Steel Aluminium Conductor Aluminium Dia Dia Dia kg/km No. Dia No. Dia Dia No. Dia mm Morochuca 3*6AWG+1*6AWG 1 1.68 6 1.68 5.04 1 4.11 4.11 1.14 6.40 14.62 221 Chola 3*6AWG+1*6AWG 1 1.68 6 1.68 5.04 7 1.55 4.66 1.14 6.95 15.62 227 Morgan 3*4AWG+1*4AWG 1 2.12 6 2.12 6.36 1 5.19 5.19 1.14 7.48 17.37 331 Hackney 3*4AWG+1*4AWG 1 2.12 6 2.12 6.36 7 1.96 5.88 1.14 8.17 18.62 338 Palomino 3*2AWG+1*2AWG 1 2.67 6 2.67 8.02 7 2.47 7.42 1.14 9.71 22.41 511 Costena 3*1/0AWG+1*1/0AWG 1 3.37 6 3.37 10.11 19 1.89 9.47 1.52 12.52 28.77 824 Grullo 3*2/0AWG+1*2/0AWG 1 3.78 6 3.78 11.35 19 2.13 10.63 1.52 13.68 31.61 1015 Suffolk 3*3/0AWG+1*3/0AWG 1 4.25 6 4.25 12.74 19 2.39 11.94 1.52 14.99 34.82 1254 Appaloosa 3*4/0AWG+1*4/0AWG 1 4.77 6 4.77 14.31 19 2.68 13.40 1.52 16.45 38.42 1554 Broneo 3*336.4+1*336.4 1 3.47 18 3.47 17.36 19 3.38 16.90 2.03 20.96 48.43 2321 Gelding 3*336.4+1*4/0AWG 1 4.77 6 4.77 14.31 19 3.38 16.90 2.03 20.96 46.59 2221
xlpe insulation abc cable workshop corner
xlpe insulation abc cable customer visit our factory
xlpe insulation abc cable packing
xlpe insulation abc cable why you choose us
Our Principles
1. Quality first, customer first, safety first
2. Better service, faster delivery
3. Equal and mutual benefit
4. Honest and professional
Why choose us?
1. Swift and professional response
2. Patient and trusty
3. Severe quality control system
4. On-time delivery
xlpe insulation abc cable pls contact with us
Contact
Leo Liu
Department sale manager
International Trade Department
Luoyang Dayuan Cable Factory Co., Ltd
=================================
Web: http://dycable.en.made-in-china.com
Alibaba Showroom: http://dycable.en.made-in-china.com
=================================
