Industrial Cables H05rnh2-F Illumination Flat Cable Rubber Sheathed Flexible Cable Electric Wire
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Underground
- Conductor Material：Copper
- Sheath Material：Rubber
- Insulation Material：Rubber
Base Info
- Model NO.：H05RNH2-F
- Material Shape：Round Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, CE, UL, CCC, RoHS, VDE
- Brand：Feiya
- Color：Black Red Yellow, According to Voltage Level
- Whether It Is Environmentally Friendly：Yes
- Whether Quality Inspection：Provide Inspection Certificate
- Standard：Customized According to Specified National Standar
- OEM/ODM：Accepted
- Core：Single Core and Multicore
- Transport Package：Standard Export Packaging
- Specification：International General Specifications
- Trademark：Fengda
- Origin：Tianjin, China(Mainland)
- HS Code：8544492100
- Production Capacity：100000,Day
Description
Application:
This cable is used in dry, humid and wet locations, as well as outdoors as a clamping cable for standardised lamp holders for the illumination of spaces and gardens.
H05RNH2-F
Construction:
1 ..... fine-stranded tinned copper
2 ..... ethylene propylene rubber (NR) or
styrene-butadiene rubber (SBR) insulation
3 ..... polychloroprene (CR) inner sheath
4 ..... polychloroprene (CR) outer sheath, green
Standards:
DIN VDE 0282
DIN EN 60228 class 5 (construction)
HD 22.8 S2:1994+A1:1999+A2:2004
Technical data:
| Nominal voltage Uo/U | [V] | 300 / 500 volt | |
| Test voltage | [V]AC | 2000 | |
| Temperature range | in motion | -25°C till +50°C | |
| Operating temperature | short circuit | °C | 200 |
| Short circuit time | max. | [sec] | 5 |
| Bending radius | min. | x diameter | 6 |
| Flammability | standard | EN 60332-1-2 |
