Purple 23AWG FTP CAT6 Communication Cable
Hangzhou Risun Cable Co., Ltd.- Type：Insulated
- Conductor Type：Solid
- Application：Integrated Wiring
- Conductor Material：Bc,Cu,CCA,Tc,CCS
- Sheath Material：PVC, PE, LSZH
- Insulation Material：HDPE
Base Info
- Model NO.：FTP Cat6
- Material Shape：Round Wire
- Certification：ISO9001, CE, RoHS, ETL SGS CPR
- Brand：Risun or OEM
- Cores：8
- Shield：Polyester Tape,Al Foil
- Drain Wire：Tinned Copper
- Transport Package：305m,Wooden Reel,CTN
- Specification：FTP CAT6
- Trademark：RISUN or OEM
- Origin：Hangzhou, China(Mainland)
- HS Code：8544491100
- Production Capacity：20000 Boxes , Month
Description
ConstructionConductor 23AWG (Solid or Strand) CU/CCA/CCS Insulation HDPE1.04±0.06mm Cores/Pairs 8/4 Drain Wire 26AWG Tinned Coppe Shield Polyester Tape AL Foil Sheath 7.30±0.1mm PVC (FR,RoHS,UV)/ LSOH / PE Elongation Min. 300% Temperature Range -20 up to +75°C Tensile strength Min. 1.68Kg/mm2 Conductor Resistance Max. 9.38 ohm/100m Resistance Unbalance Max. 2% Insulation Resistance 150 ohm/KM Mutual Capacitance Max. 5600pF/100m Cpacitance Unbalance Max. 330pF/100m Impendance 100±15 ohm Spark Test 2000V Velocity Propagation 67% Attenuation RL Next PS Next (MHz) (db/100m) (db) (db) (db/100m) 1MHz 2.0 20 65.3 63.5 4MHz 4.1 23 56.3 54.2 8MHz 5.8 24.5 52.4 50.5 10MHz 6.6 25 51.3 49.2 16MHz 8.2 25 49.3 47.4 20MHz 9.3 25 48.8 46.9 25MHz 10.4 24 45.3 43.4 31.25MHz 11.7 23 43.0 41.8 62.5MHz 17.0 21 39.2 37.2 100MHz 22.0 20 36.3 34.4 155MHz 28.1 19 35.5 33.6 200MHz 32.4 19 31.8 29.9 240MHz 36.0 18 30.6 28.7 300MHz 41.0 18 29.2 27 350MHz 44.9 17 28.0 25.6
Ordering directly from a manufacturer like us will greatly reduce your costs and makes your products more competitive in your marked.
RISUN has it's own style of carton artwork. Our carton factory support us to supply the most suitable carton for you. In addition, we also supply OEM service to our international clients.
Ordering directly from a manufacturer like us will greatly reduce your costs and makes your products more competitive in your marked.
RISUN has it's own style of carton artwork. Our carton factory support us to supply the most suitable carton for you. In addition, we also supply OEM service to our international clients.
