Low Voltage AC Cable Single Core Cable Cu/PVC/PVC
Henan Hongda Cable Co., Ltd.- Application：Construction, Underground, Industrial, Power Station
- Voltage：Low and Medium Voltage Cable
- Current：AC Cable
- Insulation Material：PVC
- Sheath Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：AC Cable
- Wire Core Material：Bare Copper Wire
- Certification：ISO, CCC, CE
- Model：AC Cable
- Brand：OEM
- Product Name：PVC Insulated and Sheathed Power Cable Cu,PVC,PVC
- Conductor：100% Copper
- Packaging：Wooden Drum
- Transport Package：Wooden Drum
- Specification：ac cable 1.5 - 630mm2
- Trademark：OEM
- Origin：China(Mainland)
- HS Code：8544492100
- Production Capacity：500 Kilometer,Month
Description
CapacityResistance at (20 ºC) Weight Lenght mm2 mm Air (A) Ground (A) Air (A) Ground (A) Ohm/Km Kg/Km Mt 1 x 1.5 re 5.8 21 27 21 27 12.1 51.3 1000 1 x 2.5 re 6.2 27 35 28 35 7.41 63.92 1000 1 x 4 re 7 37 46 38 45 4.61 87.22 1000 1 x 6 re 7.5 46 57 48 57 3.08 109.94 1000 1 x 1.5 rm 6 21 27 21 27 12.1 54.13 1000 1 x 2.5 rm 6.4 27 35 28 35 7.41 66.94 1000 1 x 4 rm 7.4 37 46 38 45 4.61 94.12 1000 1 x 6 rm 8 46 57 48 57 3.08 119.21 1000 1 x 10 rm 8.6 64 76 65 76 1.83 159.86 1000 1 x 16 rm 9.6 84 98 87 97 1.15 223.73 1000 1 x 25 rm 11.1 114 127 117 125 0.727 326.17 1000 1 x 35 rm 12.2 140 152 144 150 0.524 426.37 1000 1 x 50 rm 13.8 172 180 177 178 0.387 567.61 1000 1 x 70 rm 15.6 218 220 225 218 0.268 778.47 1000 1 x 95 rm 18 270 264 278 260 0.193 1,060.91 1000 1 x 120 rm 19.4 315 300 325 296 0.153 1,299.63 1000 1 x 150 rm 21.4 362 336 373 331 0.124 1,598.60 1000 1 x 185 rm 23.8 420 379 433 374 0.099 1,988.29 1000 1 x 240 rm 26.7 503 439 518 432 0.075 2,570.65 1000 1 x 300 rm 29.4 580 494 598 486 0.06 3,187.12 500 1 x 400 rm 33 674 558 695 549 0.047 4,079.78 500 1 x 500 rm 36.6 781 629 806 618 0.037 5,148.48 500 1 x 630 rm 40.2 901 704 930 692 0.028 6,494.98 500 2 x 1.5 re 11.6 23 27 23 27 12.1 196.07 1000 2 x 2.5 re 12.4 30 36 30 36 7.41 235.09 1000 2 x 4 re 14 40 47 40 47 4.61 312.09 1000 2 x 6 re 15 51 59 51 59 3.08 378.45 1000 2 x 1.5 rm 12 23 27 23 27 12.1 208.50 1000 2 x 2.5 rm 12.8 30 36 30 36 7.41 248.37 1000 2 x 4 rm 14.8 40 47 40 47 4.61 342.49 1000 2 x 6 rm 16 51 59 51 59 3.08 419.37 1000 2 x 10 rm 17.2 70 80 70 80 1.83 529.45 1000 2 x 16 rm 19.2 93 104 93 104 1.15 709.89 1000 2 x 25 rm 22.2 123 134 123 134 0.727 1,004.86 1000 2 x 35 rm 24.4 151 162 151 162 0.524 1,279.71 1000 2 x 50 rm 27.8 182 191 182 191 0.387 1,696.66 1000 2 x 70 rm 31.6 230 236 230 236 0.268 2,292.18 1000 2 x 95 rm 36.4 280 281 280 281 0.193 3,093.83 1000 2 x 120 rm 39.4 325 321 325 321 0.153 3,745.91 1000 2 x 150 rm 43.6 371 361 371 361 0.124 4,612.83 1000 2 x 185 rm 48.4 424 406 424 406 0.099 5,714.31 1000 2 x 240 rm 54.6 501 470 501 470 0.075 7,376.12 1000 2 x 300 rm 60.4 572 528 572 528 0.06 9,127.01 500 2 x 400 rm 67.2 634 541 634 541 0.047 11,520.03 500 3 x 1.5 re 12.1 19 23 19 23 12.1 220.73 500 3 x 2.5 re 13 26 31 26 31 7.41 270.69 500 3 x 4 re 14.7 34 40 34 40 4.61 363.56 500 3 x 6 re 15.8 44 50 44 50 3.08 449.20 500 3 x 1.5 rm 12.6 19 23 19 23 12.1 236.91 500 3 x 2.5 rm 13.4 26 31 26 31 7.41 284.28 500 3 x 4 rm 15.6 34 40 34 40 4.61 399.00 500 3 x 6 rm 16.9 44 50 44 50 3.08 495.84 1000 3 x 10 rm 18.2 60 68 60 68 1.83 641.12 1000 3 x 16 rm 20.3 79 88 79 88 1.15 871.75 1000 3 x 25 rm 23.6 105 114 105 114 0.727 1,255.50 1000 3 x 35 rm 26 129 137 129 137 0.524 1,618.37 1000 3 x 50 rm 29.8 162 168 162 168 0.387 2,164.90 1000 3 x 70 rm 33.9 203 206 203 206 0.268 2,948.27 1000 3 x 95 rm 39 250 247 250 247 0.193 3,984.13 1000 3 x 120 rm 42.6 289 281 289 281 0.153 4,895.78 1000 3 x 150 rm 46.7 330 315 330 315 0.124 5,972.13 500 3 x 185 rm 51.9 381 356 381 356 0.099 7,412.44 500 3 x 240 rm 58.5 451 412 451 412 0.075 9,578.89 500 3 x 300 rm 64.7 517 464 517 464 0.06 11,868.56 500 3 x 400 rm 72.7 594 524 594 524 0.047 15,164.95 500 3 x 10 + 6 rm 19.3 68 77 68 77 1.83 734.35 1000 3 x 16 + 10 rm 21.5 90 99 90 99 1.15 1,004.75 1000 3 x 25 + 16 rm 24.8 121 128 121 128 0.727 1,438.69 1000 3 x 35 + 16 rm 27 149 154 149 154 0.524 1,792.07 1000 3 x 50 + 25 rm 31.4 173 173 173 173 0.387 2,464.55 1000 3 x 70 + 35 rm 35.2 215 212 215 212 0.268 3,300.60 1000 3 x 95 + 50 rm 40.6 266 255 266 255 0.193 4,473.04 1000 3 x 120 + 70 rm 44.7 308 289 308 289 0.153 5,602.53 500 3 x 150 + 70 rm 48.3 357 327 357 327 0.124 6,629.44 500 3 x 185 + 95 rm 54.5 405 366 405 366 0.099 8,418.42 500 3 x 240 + 120 rm 60.6 482 425 482 425 0.075 10,710.27 500 3 x 300 + 150 rm 67 552 479 552 479 0.06 13,260.02 500 3 x 400 + 185 rm 74.9 643 545 643 545 0.047 16,830.81 500 4 x 1.5 re 12.9 22 27 22 27 12.1 256.83 1000 4 x 2.5 re 13.9 29 35 29 35 7.41 318.92 1000 4 x 4 re 15.8 39 46 39 46 4.61 434.09 1000 4 x 6 re 17 50 57 50 57 3.08 540.87 1000 4 x 1.5 rm 13.4 22 27 22 27 12.1 273.83 1000 4 x 2.5 rm 14.4 29 35 29 35 7.41 337.21 1000 4 x 4 rm 16.8 39 46 39 46 4.61 476.17 1000 4 x 6 rm 18.2 50 57 50 57 3.08 595.13 1000 4 x 10 rm 19.7 68 77 68 77 1.83 783.41 1000 4 x 16 rm 22.1 90 99 90 99 1.15 1,080.65 1000 4 x 25 rm 25.7 121 128 121 128 0.727 1,562.81 1000 4 x 35 rm 28.6 149 154 149 154 0.524 2,042.78 1000 4 x 50 rm 33.3 173 173 173 173 0.387 2,784.86 1000 4 x 70 rm 37.3 215 212 215 212 0.268 3,735.86 1000 4 x 95 rm 43.5 266 255 266 255 0.193 5,126.85 1000 4 x 120 rm 47.1 308 289 308 289 0.153 6,249.37 1000 4 x 150 rm 51.8 357 327 357 327 0.124 7,647.73 500 4 x 185 rm 57.9 405 366 405 366 0.099 9,549.82 500 4 x 240 rm 64.9 482 425 482 425 0.075 12,279.80 500 4 x 300 rm 72.2 552 479 552 479 0.06 15,310.73 500 4 x 400 rm 80.5 643 545 643 545 0.047 19,424.85 500 4 x 10 + 6 rm 21 68 77 68 77 1.83 863.19 1000 4 x 16 + 10 rm 23.5 90 99 90 99 1.15 1,179.86 1000 4 x 25 + 16 rm 27.4 121 128 121 128 0.727 1,789.97 1000 4 x 35 + 16 rm 30 149 154 149 154 0.524 2,258.01 1000 4 x 50 + 25 rm 34.9 173 173 173 173 0.387 3,100.82 1000 4 x 70 + 35 rm 39.3 215 212 215 212 0.268 4,176.07 1000 4 x 95 + 50 rm 45.8 266 255 266 255 0.193 5,724.40 1000 4 x 120 + 70 rm 49.8 308 289 308 289 0.153 7,064.90 500 4 x 150 + 70 rm 54.5 357 327 357 327 0.124 8,499.59 500 4 x 185 + 95 rm 60.9 405 366 405 366 0.099 10,670.74 500 4x 240 + 120 rm 67.9 482 425 482 425 0.075 13,625.22 500 4x 300 + 150 rm 75.7 552 479 552 479 0.06 17,005.48 500 4x 400 + 185 rm 84.2 643 545 643 545 0.047 21,495.39 500 5 x 1.5 re 13.7 23 27 23 27 12.1 294.81 1000 5 x 2.5 re 14.8 30 36 30 36 7.41 369.54 1000 5 x 4 re 17 41 47 41 47 4.61 512.97 1000 5 x 6 re 18.3 52 59 52 59 3.08 641.95 1000 5 x 1.5 rm 14.3 23 27 23 27 12.1 316.64 1000 5 x 2.5 rm 15.4 30 36 30 36 7.41 393.08 1000 5 x 4 rm 18.1 41 47 41 47 4.61 562.71 1000 5 x 6 rm 19.7 52 59 52 59 3.08 710.55 1000 5 x 10 rm 21.3 71 78 71 78 1.83 938.37 1000 5 x 16 rm 24 94 101 94 101 1.15 1,305.94 1000 5 x 25 rm 28.3 126 131 126 131 0.727 1,920.87 1000 5 x 35 rm 31.8 155 157 155 157 0.524 2,540.91 1000 5 x 50 rm 36.5 189 185 189 185 0.387 3,408.50 1000 5 x 70 rm 41.1 215 212 215 212 0.268 4,603.93 1000 5 x 95 rm 47.8 266 255 266 255 0.193 6,300.57 1000 5 x 120 rm 52 308 289 308 289 0.153 7,716.67 500 5 x 150 rm 57.6 357 327 357 327 0.124 9,513.58 500 5 x 185 rm 64 405 366 405 366 0.099 11,809.18 500 5 x 240 rm 72.1 482 425 482 425 0.075 15,264.59 500 5 x 300 rm 80 552 479 552 479 0.06 18,977.19 500 5 x 400 rm 89.2 643 545 643 545 0.047 24,083.55 500 7 x 1.5 re 14.6 14 10 14 10 12.1 346.93 1000 7 x 2.5 re 15.8 19 16 19 16 7.41 441.28 1000 7 x 1.5 rm 15.2 14 10 14 10 12.1 369.64 1000 7 x 2.5 rm 16.4 19 16 19 16 7.41 465.80 1000 10 x 1.5 re 17.6 12 9 12 9 12.1 507.92 1000 10 x 2.5 re 19.2 16 13 16 13 7.41 652.87 1000 10 x 1.5 rm 18.4 12 9 12 9 12.1 457.80 1000 10 x 2.5 rm 20 16 13 16 13 7.41 587.13 1000 12 x 1.5 re 18.1 12 9 12 9 12.1 592.78 1000 12 x 2.5 re 19.8 16 13 16 13 7.41 756.04 1000 12 x 1.5 rm 19 12 9 12 9 12.1 592.78 1000 12 x 2.5 rm 20.6 16 13 16 13 7.41 756.04 1000 14 x 1.5 re 18.9 10 8 10 8 12.1 607.95 1000 14 x 2.5 re 20.6 14 12 14 12 7.41 789.41 1000 14 x 1.5 rm 19.8 10 8 10 8 12.1 652.57 1000 14 x 2.5 rm 21.5 14 12 14 12 7.41 837.90 1000 19 x 1.5 re 20.6 9 7 9 7 12.1 744.38 1000 19 x 2.5 re 22.6 12 11 12 11 7.41 984.26 1000 19 x 1.5 rm 21.6 9 7 9 7 12.1 797.89 1000 19 x 2.5 rm 23.6 12 11 12 11 7.41 1,042.79 1000 21 x 1.5 re 21.6 9 7 9 7 12.1 820.91 1000 21 x 2.5 re 23.8 12 11 12 11 7.41 1,092.51 1000 21 x 1.5 rm 22.7 9 7 9 7 12.1 883.13 1000 21 x 2.5 rm 24.8 12 11 12 11 7.41 1,153.77 1000 24 x 1.5 re 23.6 8 6 8 6 12.1 974.64 1000 24 x 2.5 re 26 11 10 11 10 7.41 1,292.44 1000 24 x 1.5 rm 24.8 8 6 8 6 12.1 1,049.37 1000 24 x 2.5 rm 27.4 11 10 11 10 7.41 1,387.80 1000 30 x 1.5 re 24.9 8 6 8 6 12.1 1,113.94 1000 30 x 2.5 re 27.6 11 10 11 10 7.41 1,498.93 1000 30 x 1.5 rm 26.2 8 6 8 6 12.1 1,198.65 1000 30 x 2.5 rm 28.9 11 10 11 10 7.41 1,592.46 1000 40 x 1.5 re 27.8 7 5 7 5 12.1 1,412.49 1000 40 x 2.5 re 31.4 9 8 9 8 7.41 1,961.35 1000 40 x 1.5 rm 29.3 7 5 7 5 12.1 1,521.41 1000 40 x 2.5 rm 33 9 8 9 8 7.41 2,090.70 1000 48 x 1.5 re 30.9 7 5 7 5 12.1 1,713.02 1000 48 x 2.5 re 34.9 9 8 9 8 7.41 2,378.52 1000 48 x 1.5 rm 33.2 7 5 7 5 12.1 1,901.40 1000 48 x 2.5 rm 36.7 9 8 9 8 7.41 2,537.80 1000 61 x 1.5 re 33.6 6 4 6 4 12.1 2,090.22 1000 61 x 2.5 re 37.4 8 7 8 7 7.41 2,849.48 1000 61 x 1.5 rm 35.4 6 4 6 4 12.1 2,247.48 1000 61 x 2.5 rm 39.4 8 7 8 7 7.41 3,042.97 1000 Why Choose Us ?
Packing shipping
Why Choose Us ?
Quality And Safety
- Hongda Cable was founded in 1999 with almost 17 years of experience in the cable industry.
- Our manufacturing facilities are equipped with state-of-the-art technology, so we are able to meet our customers' needs for a wide range of industrial cables.
- With knowledgable engineers, rigorous quality standards and customer-centered core values, we are always ready to provide the best available products and services.
- For customers inquiring about our services, we offer product testing and sample analysis against international standards--free of charge.
Complete Inventory And Fast Delivery
- Our integrated manufacturing and storage facilities enable us to offer flexibility in specifications and fast turnaround time.
- Providing outstanding service level, Hongda Cable will meet your requirements for both standard products from our catalog and custom solutions.
Customized Solutions And Tailored Services
- With 17 years of experience, we are proud of our industry-leading R&D center and able to meet our customers' needs.
- Hongda Cable specializes in the design, manufacturing, and distribution of special industrial cable products. We welcome any ODM inquiries.
