• Model NO.：THW
• Wire Core Material：Bare Copper Wire
• Certification：ISO, CCC
• Model：Thw
• Brand：Yifang
• Transport Package：Wooden Drum or Steel Wooden Drum
• Specification：10 awg to 1,0awg
• Trademark：Yifang
• Origin：China
• HS Code：8544492100
• Production Capacity：10000m Per Week

ITEMDESCRIPTIONUNITPARAMETERPARAMETER1Rated VoltageV6002Applicable Standard----IEC 602273Phase Conductor   Conductor Material--Stranded bare copperCore number of conductor--33Conductor Cross-sectional AreaAWG810Stand constructionNos / mm19/0.7519/0.60Conductor Diameter (approx.)mm3.753DC resistance at 20ºC 2.0973.364Ground Conductor   Conductor Material--Stranded bare copperCore number of conductor--11Conductor Cross-sectional AreaAWG1010Stand constructionNos / mm19/0.6019/0.60Conductor Diameter (approx.)mm3.03.05Insulation   Insulation Material--THW 75ºC PVCTHW 75ºC PVCNominal thickness of insulationmm1.521.52Core Identification--black, yellow, red, green(ground)6Outer Sheath   Outer Sheath Material---Sunlight resistance Balck PVCNominal thickness of sheathmm1.201.207Approximate Dimensionmm26.2 x 9.223.8 x 8.48Permissible continuous working temperature of conductorºC70709Approximate Weightkg/km576451

Our company

Yifang Electric group mainly specialized in wire&cables,including designment,production and sale.

Products are mainly covering low,medium,high voltage(1KV to 220KV) XLPE Insulated power cable,PVC insulated power cable,ABC cable,building cable control cable,rubber cable welding cable Etc.

Our XLPE cable can be manufactured according to the company's specification which is equivalent to IEC 60502,IEC60332,IEC60754. Some indexes are superior to above international standard.

Our certificate


FAQ

1.Q:Are you a factory or trading company?
 A: Manufacturing base in Henan ,China, with more than 500 workers.

2.Q:How can I visit there?
 A: Sure,If you need,we will arrange the driver to pick you up.

3.Q:How can I get some samples?
 A: Contact me on below,Determin sample and address for shipping.


4.Q:Have you ever supplied cables to our country?
 A: Yifang Cables have been sold to over 100 countries and regions in the world. can you contact me for details.

5.Q:What is your MOQ?
A: MOQ Normally 500 meters for big diameter cables.Please contact me for detail info if you have specific cable requirement.

6. Q:When can I get the price?
A: Usually quote within 6 hours after we get your inquiry.

7.Q:How long is your delivery time?
 A: According to your order's quantity.Usually our lead time is 3 - 20 working days.
