PVC Ho1n2-D Building Wire PVC Insulation EV Cable Low Voltage Power Cable Flry/AVS/Avss/Qb-B/QVR Aluminium Copper Wire Low-Voltage Shielded Automobile Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Application：Construction, Overhead, Underground, Industrial, Power Station, Telecommunication, Computer, Home Wire
- Voltage：Low and Medium Voltage Cable
- Insulation Material：PVC
- Sheath Material：PVC
- Material Shape：Round Wire
- Wire Core Material：Bare Copper Wire
Base Info
- Model NO.：Power Cables
- Certification：ISO, CCC, CE
- Model：RG6,U
- Brand：Feng Da
- Colour：Red,Green,Blue,Black,White,as Request
- OEM/ODM：Yes
- Flame Test：Yes
- Intended for Use：Electric Automobile Charging Cable Material
- Rate Voltage：60V DC & 25V AC
- Temperature Rating：-30 C to +105c
- Wire Gauge：0.2mm ~ 2.5mm
- Transport Package：Rolls or According to Customer′s Request
- Trademark：feiya
- Origin：Tianjin, China
- HS Code：8544422900
Description
AWG(No of Strands/Strand Diameter)
No. of Cores x Nominal Cross Sectional Area
Nominal
Thickness of Insulation
Nominal
Thickness of Sheath
Nominal Overall Diameter
Nominal Cable Weight
No. x mm²
mm
mm
mm
kg/km
6(903/35)
1×16
1.2
2
11.0±0.5
230
4(1407/35)
1×25
1.4
2
12.5±0.5
325
2(1974/35)
1×35
1.4
2
14±0.5
440
1(2830/35)
1×50
1.6
2.2
16.5±0.5
600
2/0(3952/35)
1×70
1.6
2.4
18.5±0.5
830
3/0(5370/35)
1×95
1.8
2.6
21.0±0.5
1110
4/0(614/24)
1×120
1.8
2.8
23.5±0.5
1375
300MCM(765/24)
1×150
2
3
26±0.5
1680
350MCM(944/24)
1×185
2.2
3.2
27.5±0.5
2050
500MCM(1225/24)
1×240
2.4
3.2
30.5±0.5
2630
