• Material Shape：Round Wire
• Range of Application：LSOH
• Certification：ISO9001, CCC
• Brand：Hongda
• Color：Red Yellow Green Blue Black White Black
• Transport Package：on The Drum or on The Pallent
• Specification：10awg
• Trademark：hongda
• Origin：Henan
• HS Code：8544492100
• Production Capacity：30000m,Day

TypeTW, THWVoltage  Rate600VRange of Nominal cross section:14 AWG ~ 1000 MCMApplicationThese cables are suitable for most current wiring solutions for residential, commercial and industrial environments. It is used in service entrance, feeders and branch circuits for permanent installations. It can installed in conduits and other raceways.StandardASTM, ULConstructionsConductor: Class 1/2 Plain annealed copper wires, solid or stranded
Insulation: PVCMax. Operating TemperatureTW: 60ºC
THW: 75ºCPacking100 meter/roll or as per requirementProduction Capacity100 kilometer/ dayMOQ10000 meters for small size, 5000 meters for middle size, 1000 meters for big sizeDelivery time10~15 working daysRemarkThe cable can be of flame retardance, fire resistance and other property

TW/THW wire



 Copper conductor/PVC insulation

1.Volt 600V

2.Standars:UL 83

3.Certificate:UL

TW/THW wire Application:electric equipment, household, and electrical appliance

TW/THW wire type: (Electrial wires series include the following) :

      1. Solid copper (or aluminum) conductor, PVC insulated single core electrical wire

      2. Stranded copper conductor,  PVC insulated single core electrical wire

      3.Solid copper conductor,  PVCinsulated and PVC sheathed round multi-core electrical wire

      4.Solid or stranded copper conductor,  PVC insulated and PVC sheathed flat electrical wire(two cores or three cores)

      5.Flexible copper conductor,  PVC insulated single core electrical wire

      6. Flexible copper conductor,  PVC insulated twin parallel electrical wire

      7. Flexible copper conductor,  PVC insulated and PVC sheathed multi-core electrial wire

TW/THW wire working condition:

Conductor: Solid or  strand  annealed copper or CCA wire

Insulation: Polyvinyl Chloride (PVC 75° C  ), flame retardant, Suitable for use in wet or dry locations

TW/THW wire standard:

ASTM B3, NTC 359. :Soft copper wire.

ASTM B8, NTC 307. :Concentric Lay Stranded copper conductors.

ASTM B787. 19 :Wire Combination Unilay Stranded Copper conductors for subsequent insulation

UL 1581, NTC-3203.: Reference Standard for Electrical Wires, Cables and Flexible Cords.

UL 83, NTC-1332. :Thermoplastic insulated Wires and Cables.



TW/THW wire specification

Item Spec.AWG SIZENo./Diameter of conductor
(mm)Insulation thickness
(mm) Max.outer diameter (mm)Ref .Weight(km/kg)THW-16B167/0.490.762.819THW-14B147/0.620.763.429THW-12B127/0.780.763.942THW-10B107/0.980.764.562THW-8B87/1.231.146103THW-6B67/1.561.527.8169THW-4B47/1.961.529249THW-3B37/2.201.529.7306THW-2B27/2.471.5210.5376THW-1B119/1.682.0312.5487THW-1/0B1/019/1.892.0313.6600THW-2/0B2/019/2.122.0314.7739THW-3/0B3/019/2.382.0316912THW-4/0B4/019/2.672.0317.51130THW-16A161/1.290.762.919THW-14A141/1.630.763.227THW-12A121/2.050.763.639THW-10A101/2.590.764.159THW-8A81/3.261.145.698

FAQ

Q1: Is your company a factory or trade company ?
A: We are  factories, more than 20 years in China.



Q2: What's the quality assurance we can provide and how do we control quality?
A:100% inspection on assembly lines. All controls, inspections, equipment, fixtures, total production resources and skills are inspected to confirm they consistently achieve the required quality levels.



Q3: What's your payment terms?

A: We normally accept T/T 30% deposit, 70% balance before delivery as the main payment terms, and other payment can also be negotiated.



Trade assurance on Alibaba is also available.

Q4: What's the delivery time?

A:  Formal order needs 10-25 days.



Q5: Can I get some samples?

A: Yes, sample order is available for quality check and market test.



Q6: Do you have the products in stock?

A: Yes, we will keep some general ones in stock.



Q7; What is your MOQ?
 A: It`s base on the cable type or wire type. We also accept Small order .



Q8; Where is your factory ?
 A: we are in henan , middle of china  .
