Self Regulating Heating Cable Low Temperature

Anhui Youyu Electric Heating Equipment Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Heating
  • Conductor Material：Copper
  • Material Shape：Flat Wire
  • Range of Application：Flame Retardant

Base Info

  • Model NO.：FSL
  • Certification：ISO9001, RoHS, ISO14001
  • Sheath Material：PE,FEP,PVC or Customize
  • Insulation Material：XLPE,FEP or Customize
  • Brand：Youyu
  • Wire：Tinned Copper
  • Jacket：XLPE,FEP,PVC
  • Color：Customize
  • Working Voltage：230V or Customized
  • Max Use Length：160m
  • Max Maintain Temperature：120ºC
  • Max Withstand Temperature：205ºC
  • Transport Package：Carton
  • Specification：20W,M OR customize
  • Trademark：YOUYU
  • Origin：Anhui, China(Mainland)
  • Production Capacity：100000meters,Year

Description

TypePower
(W/M, at 10ºC)Maximum Tolerance TemperatureMaximum Maintain TemperatureMinimum
Installation TemperatureMaximum Usage Length
(based on 220V)Low
Temperature10W/M
15W/M
25W/M
35W/M105ºC65ºC±5ºC-40ºC100mMedium Temperature35W/M
45W/M
50W/M
60W/M135ºC105ºC±5ºC-40ºC100m
High
Temperature
 50W/M
60W/M200ºC125ºC±5ºC-40ºC100m
