• Model NO.：UTP Cat5e for Waterproof Cable
• Wire Core Material：Bare Copper Wire
• Certification：CE, ISO, RoHS, ETL, CPR
• Model：Network
• Brand：Risun or OEM
• Conductor：24AWG Copper
• Insulation：HDPE
• Ripcord：Yes
• Jelly：Yes
• Jacket：PE (PE+PE, PVC+PE)
• Transport Package：305m
• Specification：24AWG CU
• Trademark：RISUN or OEM
• Origin：Zhejiang, China
• HS Code：8544491100
• Production Capacity：20000 Boxes,Month

U/UTP CAT.5e PE for outdoor

Category 5e Unshielded Twisted Pair U/UTP Installation cable for outdoor use.

DESCRIPTIONManufactured according to ISO / IEC 11801, EIA / TIA-568-C.2, EN-50173.         TECHNICAL SPECIFICATIONS   Conductor Bare copper0.50±0.01 mm



Insulation HDPE 0.90±0.05 mmIdentification of pairs   1 pairBlue - White / Blue 2 pairOrange - White / Orange 3 pairGreen - White / Green 4 pairBrown - White / BrownRipcordYesJelly compoundYesSheathPEColorBlackBending radius≥ 8 x Diameter (mm) InstallationStorage temperature-15ºC-+70ºC         ELECTRICAL CHARACTERISTICS nº Pairs.xФ (mm)

Conductor

Resistance

(ohm/km)

Resistance

Unbalance

Cap. between cond. pair

(nF / 100m)

Velocity of

Propagation (%)

Impendance (ohm)ФExt. (Appvox) (mm) 4x2x0.50max.95max.4%5.669100±155.3±0.3

Frequency

(MHz)

RL  ≥dB

ATT

 ≤dB/100m

NEXT

≥dB

DELAY

 ≤ns/100m

PS NEXT

 ≥dB

EL FEXT

≥dB/100m

PS EL FEXT

≥dB/100m

 423.04.156.3552.053.352.049.0 824.55.851.8547.048.845.942.9 1025.06.550.3545.047.344.041.0 1625.08.247.2543.044.239.936.9 2025.09.345.8542.042.838.035.0 2524.310.444.3541.041.336.033.0 31.2523.611.742.9540.039.934.131.1 62.521.517.038.4539.035.428.125.1 10020.122.035.3538.032.324.021.0         ApplianceCable for data transmission in structured cabling networks (LAN), horizontal and secondary facilities.         Packing

• All sizes and values without tolerances are reference values. We reserves the right to amend this specification without prior notice.
