35 50 70 95mm Electrical Cable PVC Insulated Power Cable for Construction

Henan Hongda Cable Co., Ltd.
  • Application：Construction, Underground, Industrial, Power Station
  • Voltage：Low and Medium Voltage Cable
  • Current：DC & AC
  • Insulation Material：PVC
  • Sheath Material：PVC
  • Material Shape：Round Wire

Base Info

  • Model NO.：low voltage power cable
  • Certification：ISO, CCC, CE
  • Brand：Hongda
  • Color：as Customer Requirement
  • MOQ：500
  • Transport Package：Steel-Wooden Drum,Wooden Drum
  • Specification：As customer requirement
  • Trademark：HONGDA
  • Origin：China
  • Production Capacity：2000m,Week

Description

For laying indoors, in tunnel, cable trench, well or direct in ground, able to bear external mechanical forces and certain pulling force.VV33 (CU/PVC/SWA/PE)VLV33 (AL/PVC/SWA/PE)Cu conductor(Al conductor)PVC insulated steel-wire armored PE sheathed power cableVV72 (CU/PVC/AWA/PVC)VLV72 (AL/PVC/AWA/PVC)Cu conductor(Al conductor)PVC insulated aluminium-wire armored PVC sheathed power cableVV73 (CU/PVC/AWA/PE)VLV73 (AL/PVC/AWA/PE)Cu conductor(Al conductor)PVC insulated aluminium-wire armored PE sheathed power cable


Note: KAIQI POWER can produce "Flame-Retardant Series", "Fire-Resistant Series", "Low Smoke Halogen Free (LSHF/LSOH) Series","Low Smoke Low Halogen (LSLH) Series", etc. power cable as customer required.
Performance in line withIEC60331, IEC60332,IEC 61034,IEC60754 requirements.



5   Construction
Conductor shaped:RE=circular solid,CC=compacted circular stranded,SM=sector shaped stranded
Conductor: Plain circular ,compacted or shaped stranded copper or aluminium conductor ,conform to IEC60228 CLass 1 or Class 2
Insulation: PVC Compound Insulation
Colour identification :
1 Core: Red or Black
2 Cores: Red, Black
3 Cores: Red, Yellow, Blue
4 Cores: Red, Yellow, Blue, Black
5 Cores: Red, Yellow, Blue, Black, Green
Above 5 Cores: Black Cores with White numerals
The above identifying can be changed as order
Bedding /Inner Sheath :PVC Compound
Armour: Aluminium wire(AWA) or aluminium alloy wire(AWA), Galvanized steel wire(SWA) or steel tape(STA) ect.
Outer Sheath:PVC or PE Compound
Note: The armored material of single core cable should be non-magnetic or magnetic reduced structure. Generallly, single core armored cable (which uses steel or steel wire armored cable) only applies to DC occasions.



Paking & Shipping
35 50 70 95mm Electrical Cable PVC Insulated Power Cable for Construction


Our service

If you come to visit the factory, you can take the train or plane to zhengzhou, we can go to zhengzhou airport or railway station to pick you up, hongda company will give you the most satisfactory service.

35 50 70 95mm Electrical Cable PVC Insulated Power Cable for Construction



Inquiry Link



35 50 70 95mm Electrical Cable PVC Insulated Power Cable for Construction


FAQ

1. Q: Are you the factory or the trading company?

    A: We are the factory.

2. Q: How long is your guarantee Period?

    A: We uaually offer 1 year guarantee for our general products.

3. Q: How can I get the samples?

    A: We can make the sample order. And usually we will charge for it.

         But the samples fee will be return to you when you make the bulk order.

4. Q: Where is your factory? How can we visit your factory?

    A: Our factory located in Zhengzhou city, Henan Province. You could reach here by train and by air.

        We can pick you up in the airport and the railway station.

5. Q; What is your MOQ?

    A: It`s base on the cable type or wire type. Please contact Calder. He will let you know.
