• Model NO.：Control Cable
• Material Shape：Round Wire
• Range of Application：Power Controlling
• Certification：ISO9001, CE, CCC
• Brand：Hongda
• Transport Package：Wooden Drum or in Coil
• Specification：As your requirement
• Trademark：Hongda
• Origin：Henan, China
• HS Code：8544492100
• Production Capacity：5000000m,Month

Chinese Type

Description

Main Application

KYJV

Copper conductor XLPE insulated and PVC sheathed control cable

Laying indoors,in trenches,
in ducts and directly in ground

KYJVR

Copper conductor XLPE insulated and PVC sheathed flexible control cable

KYJVP

Copper conductor XLPE insulated and PVC sheathed control cable with
 copper tape lapping screen

Laying indoors,in trenches,
in ducts directly in ground and
other places that   interference-resistance
 is requested.

KYJVP2

Copper conductor XLPE insulated and PVC sheathed flexible control
cable with braiding screen

KYJVRP

Copper conductor XLPE insulated and PVC sheathed control cable with
 copper tape longitudinal screen

KYJVRP2

Copper conductor XLPE insulated and PVC sheathed flexible control
cable with copper tape lapping screen

KYJV22

Copper conductor XLPE insulated and PVC sheathed control cable with
 steel tape armour

For flxed installation,laying indoors,
in trenches and ducts,directly
in ground where heavier
mechanical force withstood

KYJV32

Copper conductor XLPE insulated and PVC sheathed control cable with
 steel wire armour

For laying indoor, in tunnels, ducts, conduit and direct burial

etc. Permanent place, able to bear greater mechanical force

KYJVP2-22

Copper conductor XLPE insulated and PVC sheathed steel tape armored
 control cable with copper tape lapping screen

For fixed installation,
laying indoors,in trenches
and ducts,directly in
ground where heavier
mechanical force and
interference resistance
withstood

KYJV type 450/750V(0.6/1kV) copper conductor XLPE insulated and PVC sheathed control cable to GB/T9330-2008

Cores×Nom.
Cross-section mm2

Conductor
 category

Nom. thickness of sheath

    mm

Approx.OD

mm

Approx. Weight

 kg/km

2×0.75

1

1.2

7.7

63.4

2×1.0

1

1.5

8.1

71.9

2×1.5

1

1.5

8.6

85.8

2×2.5

1

1.5

9.4

111.4

2×4.0

1

1.5

10.3

148.1

2×6.0

1

1.5

12.0

210.9

3×0.75

1

1.5

8.1

75.5

3×1.0

1

1.5

8.5

86.4

3×1.5

1

1.5

9.0

104.8

3×2.5

1

1.5

9.9

139.8

3×4.0

1

1.5

11.5

205.9

3×6.0

1

1.5

12.6

272.5

4×0.75

1

1.5

8.8

91.1

4×1.0

1

1.5

9.1

103.4

4×1.5

1

1.5

9.8

128.7

4×2.5

1

1.5

11.4

188.1

4×4.0

1

1.5

12.5

256.5

4×6.0

1

1.5

13.7

342.6

5×0.75

1

1.5

9.5

103.0

5×1.0

1

1.5

9.9

118.6

5×1.5

1

1.5

11.2

161.8

5×2.5

1

1.5

12.3

217.1

5×4.0

1

1.5

13.6

299.7

5×6.0

1

1.5

14.9

404.5

6×0.75

1

1.5

10.2

120.1

6×1.0

1

1.5

11.3

153.4

6×1.5

1

1.5

12.0

188.6

6×2.5

1

1.5

13.3

255.3

6×4.0

1

1.5

14.7

355.3

6×6.0

1

1.7

16.2

480.7

7×0.75

1

1.5

10.2

126.4

7×1.0

1

1.5

11.3

161.7

7×1.5

1

1.5

12.0

201.1

7×2.5

1

1.5

13.3

275.1

7×4.0

1

1.5

14.7

387.1

7×6.0

1

1.7

16.2

528.2

8×0.75

1

1.5

11.6

159.2

8×1.0

1

1.5

12.1

183.5
