RV-K Power Cable, 0.6/1 Kv, Flexible Cu/XLPE/PVC (UNE 21123-2/EN 50265)
Jiangsu Boan Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Underground
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：XLPE
Base Info
- Model NO.：RV-K
- Material Shape：Round Wire
- Range of Application：Installation
- Certification：ISO9001, CE, CCC
- Brand：Boan
- Rated Voltage：0.6,1 Kv
- Number of Cores：1-5
- Class of Conductor：5
- Size：2.5-630 Mm2
- Transport Package：Heated Steel-Wooden Drum,Wooden Drum
- Specification：SGS
- Trademark：DingAn or OEM
- Origin：Jiangsu Yixing, China
- HS Code：8544492100
- Production Capacity：38000 Km,Year
Description
| No. of Cores x Nominal Cross Sectional Area | Nominal Thickness of Insulation | Nominal Overall Diameter | Nominal Weight |
| No. x mm² | mm | mm | kg/Km |
| RV-K Powerflex Cable - 1 Core | |||
| 1 x 2.5 | 0.7 | 6.2 | 54 |
| 1 x 4.0 | 0.7 | 6.7 | 70 |
| 1 x 6.0 | 0.7 | 7.3 | 90 |
| 1 x 10.0 | 0.7 | 8.2 | 133 |
| 1 x 16.0 | 0.7 | 9.2 | 189 |
| 1 x 25.0 | 0.9 | 11.0 | 284 |
| 1 x 35.0 | 0.9 | 12.1 | 381 |
| 1 x 50.0 | 1.0 | 13.8 | 517 |
| 1 x 70.0 | 1.1 | 15.7 | 712 |
| 1 x 95.0 | 1.1 | 17.6 | 923 |
| 1 x 120.0 | 1.2 | 19.2 | 1165 |
| 1 x 150.0 | 1.4 | 21.5 | 1446 |
| 1 x 185.0 | 1.6 | 23.9 | 1748 |
| 1 x 240.0 | 1.7 | 26.9 | 2280 |
| 1 x 300.0 | 1.8 | 29.6 | 2829 |
| 1 x 400.0 | 2.0 | 33.8 | 3731 |
| 1 x 500.0 | 2.2 | 37.4 | 4776 |
| 1 x 630.0 | 2.4 | 42.7 | 6276 |
| RV-K Powerflex Cable - 2 Cores | |||
| 2 x 1.5 | 0.7 | 8.2 | 90 |
| 2 x 2.5 | 0.7 | 9.2 | 120 |
| 2 x 4.0 | 0.7 | 10.3 | 161 |
| 2 x 6.0 | 0.7 | 11.3 | 211 |
| 2 x 10.0 | 0.7 | 13.2 | 316 |
| 2 x 16.0 | 0.7 | 14.9 | 450 |
| RV-K Powerflex Cable - 3 Cores including Earth Core | |||
| 3 x 1.5 | 0.7 | 8.9 | 108 |
| 3 x 2.5 | 0.7 | 9.8 | 144 |
| 3 x 4.0 | 0.7 | 11.0 | 198 |
| 3 x 6.0 | 0.7 | 12.1 | 263 |
| 3 x 10.0 | 0.7 | 14.3 | 405 |
| RV-K Powerflex Cable - 3 Cores | |||
| 3 x 16.0 | 0.7 | 16.4 | 593 |
| 3 x 25.0 | 0.9 | 21.3 | 975 |
| 3 x 35.0 | 0.9 | 24.1 | 1319 |
| 3 x 50.0 | 1.0 | 27.8 | 1812 |
| 3 x 70.0 | 1.1 | 30.8 | 2463 |
| RV-K Powerflex Cable - 4 Cores including Earth Core | |||
| 4 x 1.5 | 0.7 | 9.7 | 129 |
| 4 x 2.5 | 0.7 | 10.7 | 175 |
| 4 x 4.0 | 0.7 | 12.0 | 243 |
| 4 x 6.0 | 0.7 | 13.4 | 328 |
| 4 x 10.0 | 0.7 | 15.7 | 505 |
| RV-K Powerflex Cable - 4 Cores | |||
| 4 x 16.0 | 0.7 | 18.2 | 749 |
| 4 x 25.0 | 0.9 | 24.1 | 1245 |
| 4 x 35.0 | 0.9 | 26.3 | 1671 |
| 4 x 50.0 | 1.0 | 31.3 | 2313 |
| 4 x 70.0 | 1.1 | 36.1 | 3204 |
| 4 x 95.0 | 1.1 | 40.2 | 4126 |
| 4 x 120.0 | 1.2 | 44.6 | 5245 |
| 4 x 150.0 | 1.4 | 49.8 | 6573 |
| 4 x 185.0 | 1.6 | 56.1 | 8050 |
| 4 x 240.0 | 1.7 | 64.5 | 10695 |
| RV-K Powerflex Cable - 5 Cores including Earth Core | |||
| 5 x 1.5 | 0.7 | 10.4 | 153 |
| 5 x 2.5 | 0.7 | 11.6 | 213 |
| 5 x 4.0 | 0.7 | 13.2 | 298 |
| 5 x 6.0 | 0.7 | 14.7 | 403 |
| 5 x 10.0 | 0.7 | 17.2 | 624 |
| 5 x 16.0 | 0.7 | 20.2 | 931 |
| 5 x 25.0 | 0.9 | 25.6 | 1555 |
| 5 x 35.0 | 0.9 | 29.3 | 2076 |
| 5 x 50.0 | 1.0 | 34.5 | 2878 |
