0.05 mm*1.8 mm Copper Ribbon Flat Wire For Enameled wire
GENERAL CLAD CO., LTD.- Application：Automobile, Home Appliance, solar modules
- Wire Core Material：Flat wire
- Industry Type：Photovoltaic modules
- Signal：High Voltage Wiring Harness
- Shape：Rectangular
- Certification：RoHS, ISO9001
Base Info
- Model NO.：0.05 mm*1.8 mm
- Transport Package：Platter
- Specification：0.05 mm*1.8 mm
- Trademark：General Clad
- Origin：China
- Production Capacity：2000 Tons,Month
Description
Base material copper:
- In accordance with EU-standard: DIN EN 13602 (Cu-ETP, Cu-ETP1, Cu-Of, Cu-Of1)
- In accordance with US-standard: ASTM B 224 - 80
- Available in different strength classes according to DIN EN 13599
Optional coating on the base material:
- Tin (Sn),
- Silver (Ag),
- Nickel (Ni),
- and others on request
Dimensions:
- Thickness from 0.017 to 1.200 mm
- Width from 0.200 to 24.000 mm*
*> 6.000 mm width made of cut strip, re-rolled
Designs:
- Additional application-optimized strengths to your specifications available
- Edge shape: Milled round, cut
Features:
- Geometrical and mechanical values are reviewed and documented according to your requirements
- Tightest tolerances in terms of thickness and width
- Resistance measurement to defined specifications
- Manufactured to your customized specifications
Applications:
- Fuse wire or fusible conductor for safety fuses
- Welding wire
- Connecting wire
- Wire connector (PIN)
- Shielding wire for high-frequency cable (HF cable)
