Suitable for Duct or Aerial Application Loose Tube Fiber Optical GYTS Cable

Hangzhou Softel Optic Co., Ltd.
  • Application：Fiber Optic Cable
  • Conductor Material：Fiber
  • Cover Material：PE
  • Type：Customized
  • Material Shape：Hollow Line
  • Conductor Type：Stranded

Base Info

  • Model NO.：GYTS cable
  • Wire Core Material：Steel
  • Certification：CE, ISO
  • Model：GYTS
  • Brand：Softel
  • Apply for：Directly Burial
  • Fiber Count：2-144cores
  • Cable Type：Sm or Mm
  • Fiber Type：Customerized
  • Material of Jacket：MDPE,HDPE
  • Fiber Optic Cable Tube：Central Loose Tube
  • Model Name：Fiber Optic Cable
  • Model No.：GYTS
  • Delivery Time：10 Days
  • MOQ：2 Drum
  • Transport Package：4km Wooden Drum
  • Specification：size
  • Trademark：SOFTEL
  • Origin：China
  • HS Code：85176229
  • Production Capacity：1000km Per Month

Description

DesignationMax. numberSteel wire/ standStrandedNominal cableNominal cableOf fibers per tubeDiameter (mm)unitsdiameter (mm)weight (kg/km)GYTS-2-3061.6510.6108GYTS-32-3662.3611.3135GYTS-38-60122.0512.0140GYTS-62-72122.3612.8165GYTS-74-120122.31016.5246GYTS-122-144122.31218.5300
Mechanical & Environmental CharacteristicsItem Characteristics GYTS-2-60 GYTS-62-144Tensile Strength1500N 3000NCrush Resistance1000N/100mmDuring Installation 20 Times Cable Diameter After Installation 10 Times Cable Diameter Temperature Range   Storage -50°Cto+70°C Operating -40°Cto +60°C
