Sm Simplex Sc Connector Fiber Optic Patchcord

Wuhan Seifree Technology Co., Ltd.
  • Application：Communication, Sensor, Medicine, Probe
  • Type：Single-mode Fiber
  • Connection Structure：SC
  • Material Shape：Round Wire
  • Allowed Lateral Pressure：100(N,100mm)
  • Allowed Tensile Strength：<100N

Base Info

  • Model NO.：SOFC-1-SU-SA-E-3-0-C-10
  • Core：Single Core
  • Certification：RoHS, ISO9001
  • Brand：OEM
  • Sheath Material：PVC
  • Connector Type：Sc,APC & Sc,Upc
  • Fiber Type：G652D
  • Jacket Type：PVC
  • Pigtail Diameter：3mm
  • Pigtail Length：100cm
  • Application 1：FTTH
  • Application 2：CATV
  • Application 3：ODF
  • Application 4：Gepon
  • Application 5：Olt
  • Transport Package：Plastic Bag
  • Specification：silica fiber
  • Trademark：Seifree
  • Origin：Wuhan, Hubei
  • HS Code：85367000
  • Production Capacity：10, 000 PCS,Month

Description

CableFirst EndSecond EndFiber TypePigtail Dia.(mm)Fan Out LengthJacket TypeLength1=1FiberFU(A)=FC/UPC(APC)FU(A)=FC/UPC(APC)H=Hi 78009=Φ0.905=50cmE=PE05=50cm2=2FiberSU(A)=SC/UPC(APC)SU(A)=SC/UPC(APC)F=Flex 10602=Φ2mm10=100cmC=PVC10=100cm4=4Fiber......D=G652D3=Φ3mm...H=LSZH... LU(A)=LC/UPC(APC)LU(A)=LC/UPC(APC)A=G657A...20=200cmA=Armored20=200cmR=RibbonX=CustomizationB=G657BX=Customization  W=Bow-type   OM1=62.5/125   OM2=50/125   OM3=50/125   OM4=50/125
ValueConnector/FC ST SC LCFerrule/PCUPCAPC(Step)APC(Conical)Fiber Type/SMMMSMMMSMMMSMMMInsertion LossdB<0.25<0.20<0.25<0.20<0.30/<0.30/RepeatabilityTime>1000InterchangeabilitydB<0.10Return LossdB>45>36>50>36>60/>60/Sm Simplex Sc Connector Fiber Optic PatchcordSm Simplex Sc Connector Fiber Optic PatchcordSm Simplex Sc Connector Fiber Optic PatchcordFAQ
1.Is your company a manufacturer or dealer?
 ---We have our own factory in Wuhan, China.

2.Can you provide free samples for us?
 ---Sure, we can provide free samples for you, but the freight should be paid by you.

3.What's the lead time for all the goods that I required?
 ---It depend on the quantity of products. Generally, it would be 1-2 weeks.

4.What's the warranty for your products?
 ----Normally it is 1 year.

5.What's your payment term?
 ---It is 100% T/T in advance.

6.What's the MOQ for your products?
 ---1pcs is okay.
