PVC Insulated and Jacket Electric Cable with Mylar Shield for LED Light Power Cord

B&T (Zhangzhou) Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：for General Purpose Internal Wiring of Appliance
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：PVC

Base Info

  • Model NO.：UL2464
  • Material Shape：Round Wire
  • Range of Application：Flame Retardant
  • Certification：ISO9001, UL, RoHS, Reach
  • Brand：B&T
  • Rated Temperature：80 C
  • Rated Voltage：300V
  • Ref.Standard：UL Subject758, UL1581, C22.2
  • Flame Rating：VW-1
  • Guage：20AWG
  • Halogen Free：Hf
  • Core：Multi Cores
  • Shield：Yes
  • Marking：General, OEM
  • Transport Package：610feet in Roll
  • Specification：2pin 20 AWG 2 Conductors
  • Trademark：B&T
  • Origin：Xiamen, Fujian
  • HS Code：8544492100
  • Production Capacity：300, 000km

Description

Rated Temperature80ºCRated Voltage300VStandardAWG/NO.OFCONDNO.of CondInsulated Thick.Braid shield Jacket Thick.Outside Thick. No./mmmmm/n/dmmmm24×2C11/0.160.25 16/4/0.100.80 4.35 24×3C11/0.160.25 16/4/0.100.80 4.50 24×4C11/0.160.25 16/5/0.100.80 4.80 24×5C11/0.160.25 16/6/0.100.80 5.10 24×6C11/0.160.25 16/6/0.100.80 5.45 24×7C11/0.160.25 16/6/0.100.80 5.50 22×2C17/0.160.25 16/5/0.100.80 4.75 22×3C17/0.160.25 16/6/0.100.80 4.95 22×4C17/0.160.25 16/6/0.100.80 5.30 22×5C17/0.160.25 16/7/0.100.80 5.65 22×6C17/0.160.25 16/8/0.100.80 6.05 22×7C17/0.160.25 16/8/0.100.80 6.10
