Flat Elevator Cable with Steel Wire Shield Festoon Elevator Traveling Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Heating, Underground
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Model NO.：Elevator cable
- Material Shape：Flat Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, CE, UL, CCC, RoHS, VDE
- Brand：Feiya
- Color：Black Red Yellow, According to Voltage Level
- Whether It Is Environmentally Friendly：Yes
- Whether Quality Inspection：Provide Inspection Certificate
- Standard：Customized According to Specified National Standar
- OEM/ODM：Accepted
- Core：Single Core and Multicore
- Transport Package：Standard Export Packaging
- Specification：International General Specifications
- Trademark：Fengda
- Origin：Tianjin, China(Mainland)
- HS Code：8544492100
Description
DIMENSIONS| NO. OF | NOMINAL CROSS | NOMINAL DIAMETER | NOMINAL THICKNESS | CABLE DIMENSIONS | NOMINAL |
| CORES | SECTIONAL AREA | OVER CONDUCTOR | OF INSULATION | WIDTH | WEIGHT |
| mm2 | mm | mm | mm | kg/km |
| 6 | 0.75 | 1.3 | 0.6 | 72 | 118 |
| 12 | 0.75 | 1.3 | 0.6 | 128 | 227 |
| 18 | 0.75 | 1.3 | 0.6 | 184 | 336 |
| 20 | 0.75 | 1.3 | 0.6 | 208 | 376 |
| 24 | 0.75 | 1.3 | 0.6 | 248 | 450 |
