• Wire Core Material：Red Copper Wire
• Certification：ISO, CCC, CE, RoHS, UL, VDE
• Model：Yjv;Yjy;Yjv22;Yjy23;Wdz-Yjy;Wdz-Yjy23
• Brand：Feiya
• Can Be Customized：-5 Degree Till +70 Degree
• Rated Voltage：0.6,1kv
• OEM&ODM：Yes
• Operating Environment：Underground
• Material：PVC,PE Jacket
• Other Service：Can Be Customized
• Use Place：Power Transmission and Distribution
• Low Smoke Zero Halogan：LSZH, Lsoh, Ls0h, Lsfh, Ohls
• Colors：Can Be Customized
• Other Name：Na2xry,Na2xrh,N2xny,Naxcy,Yxc7V,Naxsy,Nyfgby
• Other EU Type：RV , U-1000 R2V
• Aluminum EU Type：RV Al , U-1000 Ar2V
• Chinese Nomenclature：VV, Yjv, Yjv22, Yjv32
• Low Smoke Halogen Free：Can Be Customized
• Fire Resistant：Can Be Customized
• Transport Package：Rolls or According to Customers′ Request
• Specification：Nominal Cross section Area: 1.5-300mm2; 1.5-400mm2
• Trademark：Fengda
• Origin：Tianjin, China
• HS Code：8544421900

Basic Info.

Wire Core Material Red Copper Wire Certification ISO, CCC, CE, RoHS, UL, VDE Model Yjv;Yjy;Yjv22;Yjy23;Wdz-Yjy;Wdz-Yjy23 Brand Feiya Can Be Customized -5 Degree Till +70 Degree Rated Voltage 0.6/1kv OEM&ODM Yes Operating Environment Underground Material PVC/PE Jacket Other Service Can Be Customized Use Place Power Transmission and Distribution Low Smoke Zero Halogan LSZH, Lsoh, Ls0h, Lsfh, Ohls Colors Can Be Customized Other Name Na2xry/Na2xrh/N2xny/Naxcy/Yxc7V/Naxsy/Nyfgby Other EU Type RV / U-1000 R2V Aluminum EU Type RV Al / U-1000 Ar2V Chinese Nomenclature VV/ Yjv/ Yjv22/ Yjv32 Low Smoke Halogen Free Can Be Customized Fire Resistant Can Be Customized Transport Package Rolls or According to Customers′ Request Specification Nominal Cross section Area: 1.5-300mm2; 1.5-400mm2 Trademark Fengda Origin Tianjin, China HS Code 8544421900

Product Description

35kv Copper Conductor 133% Insulation 1/0 2/0 3/0 Size Level Mv-90/Mv-105 Urd Power Cable


1 Application:
 It is used to transmit and distribute power in power transmission and distribution systems of 35kV or lower. It is generally applied to the fields including power, construction, mines, metallurgy, petrochemical industry and communication in complete replace of oil immersed paper insulated power cable and in partial replace of PVC insulated power cable. Power cables for power networks, underground, outdoors and in cable ducting.

Standard: BS6622, BS EN/IEC 60228,IEC60502.2
Conductor: Class 2 stranded plain copper conductor to BS EN 60228:2005 (previously BS6360)
Conductor screen: Semiconducting material
Insulation: XLPE (Cross-Linked Polyethylene) Type GP8 to BS7655
Insulation Screen: Semi-conducting material
Metallic Screen: Individual and overall copper tape screen to BS6622
Filler: PET (Polyethylene Terephthalate) fibers
Separator: Binding tape
Bedding: PVC (Polyvinyl Chloride) Type TM1 to BS7655
Armoring:

Single Core: Aluminium Wire Armoured (AWA)
MultiCore: Steel Wire Armoured (SWA)
Sheath: PVC (Polyvinyl Chloride) Type TM1 to BS7655
Colour: Red or Black

2. Using features :Medium Voltage Power Cable Underground 11kv 15kv 33kv XLPE Power Cable

1. Rated voltage: Uo/U:3.6/6kV, 6/10kV(11kV), 12/20kV(24kV), 19/33kV, 26/35kV(35kV).
2. No. of core: Single-core or three cores.
3. The highest allowed operating temperature of conductor for long-term working is 90oC. In short-circuit (Max. long-term is no more than 5 seconds). The highest temperature for a conductor is no more than 250ºC.
4. D.C. resistance of the conductor complies with the stipulations of 3.6/6kV, 6/10kV(11kV), 12/20kV(24kV), 19/33kV, 26/35kV(35kV).
5. The environment temperature should be no lower than 0oC when lay. Otherwise, it should be preheated.
6. The cable is laid without a horizontal drop limit.
7. Working Frequency Voltage Test: 3.5Uo/5min without puncture.
8. Partial Discharge Test: The discharge volume should be no more than 10pC under 1.73Uo for the cable.
9. Minimum Bending Radius: Single core - Fixed: 15 x overall diameter;3 core - Fixed: 12 x overall diameter
(Single core 12 x overall diameter and 3 core 10 x overall diameter where bands are positioned adjacent to joint or terminations provided that the bending is carefully controlled by the use of a former)
Note: The single-core armored cables are used for the D.C. system only. If used for the A.C. system, the magnetic isolation should be applied to the steel armor wires of non-magnetical materials that should be used.

3. Structure
