Tight Buffer Fiber Gjpfjv Fiber Cable

Zhejiang Fuchunjiang Photoelectric Science Technology Co., Ltd.
  • Application：Communication
  • Type：Multi-mode Fiber
  • Connection Structure：SC
  • Material Shape：Round Wire
  • Allowed Lateral Pressure：>1000(N,100mm)
  • Allowed Tensile Strength：>10000N

Base Info

  • Model NO.：Gjpfjv
  • Core：Multicore
  • Certification：RoHS, UL, CE, ISO9001, VDE, CCC
  • Brand：OEM
  • Sheath Material：PVC
  • Transport Package：Wooden or as Your Request
  • Specification：2km 3km
  • Trademark：FCJ OPTO TECH
  • Origin：China
  • HS Code：854470000
  • Production Capacity：30, 000, 000km,Year

Description

Bandwidth  (Class A)@850  ≥500MHZ·km≥200MHZ·km@1300  ≥1000MHZ·km≥600MHZ·kmNumerical Aperture   0.200±0.015NA0.275±0.015NACable Cut-off Wavelength ≤1260nm≤1480nm

Technical Parameters
Fiber CountCable Diameter
mm		Cable Weight
Kg/km		Tensile Strength
Long/Short Term
N		Crush Resistance
Long/Short Term
N/100m		Bending Radius
Static/Dynamic
mm
2413.8±0.570500/1300300/100030D/15D
4818.0±0.5150500/1300300/100030D/15D
9625.0±0.5340500/1300300/100030D/15D
12031.0±1mm530500/1300300/100030D/15D
Environmental Characteristics
Transport Temperature-20ºC~+60ºC
Storage Temperature-20ºC~+60ºC
Installation Temperature-5ºC~+50ºC
Operating Temperature-20ºC~+60ºC
