5/16" 7h Ehs Galvanized Steel Wire ASTM A475
YIFANG ELECTRIC GROUP INC.- Application：Overhead
- Voltage：High Voltage Cable
- Current：DC & AC
- Insulation Material：Bare
- Sheath Material：None
- Material Shape：Round Wire
Base Info
- Model NO.：GSW 5,16"
- Wire Core Material：Steel
- Certification：ISO, CCC, CE, UL
- Model：5,16" Gsw
- Brand：Yifangcable
- Size：5,16"
- Standard：ASTM A475
- Strands：7
- Transport Package：Wooden Drum
- Specification：1.1m Drum
- Trademark：Yifang Cable
- Origin：China
- HS Code：7614900000
- Production Capacity：1000km,Month
Description
TECHNICAL DATA FOR Cable Ac. Galv. 5/16" 7H Grado Ehs NO DESCRIPTION UNIT DATA 1 Type/ code name -- 5/16" 2 Material -- Galvanized Steel Wire 3 Standards -- ASTM A475 4 Gavanized Class - Class A 5 Cross Section Area mm2 38.32 6 Conductor construction Wire No. No.s 7 Nominal wire dia. mm 2.64 7 Approx. Overall Diameter mm 7.92 8 Approx. Weight kg/km 302 9 Min.Breaking Strength kN 49.82
