XLPE Insulated N2xch Lozh Power Cable

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Industrial Cable
  • Conductor Material：Copper
  • Sheath Material：LSZH
  • Insulation Material：XLPE

Base Info

  • Model NO.：N2XCH
  • Material Shape：Round Wire
  • Range of Application：LSOH
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemN2XCHConductorRE: Class 1 solid copper
RM:: Class 2 circular stranded copper
SM: Class 2 sectorial stranded copperInsulationXLPE (Cross-Linked Polyethylene)Inner sheathHalogen-free compoundConcentric ConductorCopper wires with counter helix of copper tapeOuter SheathLSZH (Low Smoke Zero Halogen) cross-linked compoundRated Voltage 0.6/1kVMinimum Bending Radius15 x overall diameterTemperature RangeFixed: -30°C to +90°CColorOptionalApplicationA low smoke zero halogen, flame retardant power cable. For fixed indoor and outdoor installations as well as in concrete, but not for direct burial in ground or application in water.
