• Model NO.：HG Series
• Specification：304 Stainless Steel
• Trademark：HarshMet
• Origin：China
• HS Code：851770900
• Production Capacity：50000PCS Per Month

Basic Info.

Model NO. HG Series Specification 304 Stainless Steel Trademark HarshMet Origin China HS Code 851770900 Production Capacity 50000PCS Per Month

Product Description

Wire Mesh Cable Socks/Bus Drop Support Grips

1. Bus drop grips are woven of galvanized steel/304 Stainless Steel wire
2. Relieve any direct tension from the critical connection and absorb vibration and flexing
3. Offered with either the single eye or locking bale attachment
4. Bus drop grips are used as cable support from bus duct
5. Optional bus drop safety spring can be used with single eye type of disassembling draw bar from coll, placing through eye loop and replacing draw bar
6. Single eye for use when cable is vertical and for applications where cable bends
7. Locking bale attachment fits around beam or pipe and can be locked in place

Specification


Part Number	Cable Diameter	Bale Length	Mesh Length	Approx Break Strength
HG-22	0.22-0.32"(5.6-8.1mm)	9"(228.6mm)	3.5"(88.9mm)	1100 lbs.
HG-30	0.30-0.43"(7.6-10.9mm)	9"(228.6mm)	4.5"(114.3mm)	1100 lbs.
HG-41	0.41-0.56"(10.4-14.2mm)	9"(228.6mm)	5.0"(127.0mm)	1100 lbs.
HG-53	0.53-0.73"(13.5-18.5mm)	9"(228.6mm)	6.5"(165.1mm)	1100 lbs.
HG-70	0.70-0.85"(17.8-21.6mm)	9"(228.6mm)	8.5"(215.9mm)	1900 lbs.
HG-82	0.82-1.00"(20.8-25.4mm)	9"(228.6mm)	8.5"(215.9mm)	1900 lbs.
HG-96	0.96-1.25"(24.4-31.8mm)	9"(228.6mm)	11.0"(279.4mm)	1900 lbs.
