450/750V H07rn-F 4mm2 6mm2 10mm2 16mm2 25mm2 35mm2 Copper Conductor Epr Insulated Welding Flexible Electric Rubber Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：AC , DC Power Cables, Control Cables, Computers
- Conductor Material：Copper
- Sheath Material：Rubber
- Insulation Material：Rubber
Base Info
- Model NO.：H07RN-F YCW
- Material Shape：Round Wire
- Range of Application：AC , DC Power Cables, Control Cables, Computers
- Certification：ISO9001, CE, UL, CCC, RoHS, VDE
- Brand：Feiya
- OEM：Yes
- Transport Package：Wooden Box Packing or Pallet Shipping Containers
- Specification：copper
- Trademark：Feiya
- Origin：China
- HS Code：854449210
- Production Capacity：80000 Meter,Meters Per Month
Description
Flexible Rubber Insulated Cable
Application:
H07RN-F flexible rubber cable is a heavy-duty rubber sheathed cable for use on heavy equipment, such as machine tools and agricultural machinery, cabel h07rn-f is exposed to high stress in dry and damp rooms as well as outdoors and in damp industrial environments. Constant, operational movements, the use of these cables in moving cable carriers, respectively on motor drum guides or a stress of more than 15 N/mm² is not permitted.
Standard:
EN 50525-2-21, EN 60228
Flame Retardant according toIEC/EN60332-1-2
Conductor: Class 5 flexible copper conductor
Insulation: EPR (Ethylene Propylene Rubber)
Sheath: PCP (Polychloroprene)
Voltage Rating (Uo/U): 450/750V
Temperature Rating :
Fixed: -30°C to +60°C
Fixed protected installations: +85°C
Flexed: -15°C to +60°C
Minimum Bending Radius:
Fixed: 4 x overall diameter
Flexed: 6 x overall diameter
H07RN-F Single Core Type 450/750V EPR/PCP Trailing Rubber Cable
| Core and Size (mm2) | Stranding (Number of Strand / Strand Diameter) | Thickness of Sheath (mm) | Nominal Overall Diameter (mm) | Approx Weight (kg/km) |
| 1x1.5 | 30/0.25 | 0.8 | 6 | 49 |
| 1x 2.5 | 50/0.25 | 0.9 | 6.6 | 63 |
| 1x4 | 56/0.30 | 1 | 7.6 | 92 |
| 1x6 | 84/0.30 | 1 | 8.3 | 115 |
| 1x10 | 80/0.40 | 1.2 | 10.7 | 189 |
| 1x16 | 126/0.40 | 1.2 | 12 | 260 |
| 1x25 | 196/0.40 | 1.4 | 14.1 | 369 |
| 1x35 | 276/0.40 | 1.4 | 15.8 | 500 |
| 1x50 | 396/0.40 | 1.6 | 18.3 | 689 |
| 1x70 | 360/0.50 | 1.6 | 20.7 | 918 |
| 1x95 | 475/0.50 | 1.8 | 23.4 | 1202 |
| 1x120 | 608/0.50 | 1.8 | 25.6 | 1489 |
| 1x150 | 756/0.50 | 2 | 28.3 | 1824 |
| 1x185 | 925/0.50 | 2.2 | 31 | 2202 |
| 1x240 | 1221/0.50 | 2.4 | 34.5 | 2847 |
| 1x300 | 1525/0.50 | 2.6 | 37.7 | 3495 |
| 1x400 | 2013/0.50 | 2.8 | 37.7 | 3495 |
| 1x500 | 1769/0.60 | 3 | 37.7 | 3495 |
| 1x630 | 2257/0.60 | 3 | 37.7 | 3495 |
H07RN-F 2 Core Type 450/750V EPR/PCP Trailing Rubber Cable
| Core and Size (mm2) | Stranding (Number of Strand / Strand Diameter) | Thickness of Sheath (mm) | Nominal Overall Diameter (mm) | Approx Weight (kg/km) |
| 2 X 1.0 | 32/0.20 | 0.8 | 8.4 | 98 |
| 2 X 1.5 | 30/0.50 | 0.8 | 9.4 | 116 |
| 2 X 2.5 | 50/0.25 | 0.9 | 11 | 164 |
| 2 X 4.0 | 56/0.30 | 1 | 12.8 | 232 |
| 2 X 6.0 | 84/0.30 | 1 | 14.2 | 297 |
| 2 X 10.0 | 80/0.40 | 1.2 | 20.4 | 573 |
| 2 X 16.0 | 126/0.40 | 1.2 | 23 | 774 |
| 2 X 25.0 | 196/0.40 | 1.4 | 27.4 | 1110 |
| 2 X 35.0 | 276/0.40 | 1.4 | 30.8 | 1474 |
H07RN-F 3 Core Type 450/750V EPR/PCP Trailing Rubber Cable
| Core and Size (mm2) | Stranding (Number of Strand / Strand Diameter) | Thickness of Sheath (mm) | Nominal Overall Diameter (mm) | Approx Weight (kg/km) |
| 3 X 1.0 | 32/0.20 | 0.8 | 9 | 108 |
| 3 X 1.5 | 30/0.50 | 0.8 | 10.3 | 141 |
| 3 X 2.5 | 50/0.25 | 0.9 | 11.8 | 200 |
| 3 X 4.0 | 56/0.30 | 1 | 13.7 | 285 |
| 3 X 6.0 | 84/0.30 | 1 | 15.2 | 371 |
| 3 X 10.0 | 80/0.40 | 1.2 | 21.9 | 712 |
| 3 X 16.0 | 126/0.40 | 1.2 | 24.7 | 971 |
| 3 X 25.0 | 196/0.40 | 1.4 | 29.4 | 1394 |
H07RN-F 4 Core Type 450/750V EPR/PCP Trailing Rubber Cable
| Core and Size (mm2) | Stranding (Number of Strand / Strand Diameter) | Thickness of Sheath (mm) | Nominal Overall Diameter (mm) | Approx Weight (kg/km) |
| 4 X 1.0 | 32/0.20 | 0.8 | 10 | 134 |
| 4 X 1.5 | 30/0.25 | 0.8 | 11.2 | 174 |
| 4 X 2.5 | 50/0.25 | 0.9 | 12.6 | 249 |
| 4 X 4.0 | 56/0.30 | 1 | 15.1 | 361 |
| 4 X 6.0 | 84/0.30 | 1 | 16.9 | 480 |
| 4 X 10.0 | 80/0.40 | 1.2 | 24 | 890 |
| 4 X 16.0 | 126/0.40 | 1.2 | 27 | 1225 |
| 4 X 25.0 | 196/0.40 | 1.4 | 32.6 | 1792 |
| 4 X 35.0 | 276/0.4 | 1.4 | 36.5 | 2380 |
| 4 X 50.0 | 396/0.4 | 1.6 | 42 | 3635 |
| 4 X 70.0 | 360/0.5 | 1.6 | 49 | 4830 |
| 4 X 95.0 | 475/0.5 | 1.8 | 55 | 6320 |
H07RN-F 5 Core Type 450/750V EPR/PCP Trailing Rubber Cable
| Core and Size (mm2) | Stranding (Number of Strand / Strand Diameter) | Thickness of Sheath (mm) | Nominal Overall Diameter (mm) | Approx Weight (kg/km) |
| 5 X 1.0 | 32/0.20 | 0.8 | 11 | 170 |
| 5 X 1.5 | 30/0.50 | 0.8 | 12.3 | 218 |
| 5 X 2.5 | 50/0.25 | 0.9 | 14.5 | 309 |
| 5 X 4.0 | 56/0.30 | 1 | 16.9 | 450 |
| 5 X 6.0 | 84/0.30 | 1 | 18.8 | 595 |
| 5 X 10.0 | 80/0.40 | 1.2 | 26.5 | 1100 |
| 5 X 16.0 | 126/0.40 | 1.2 | 30 | 1528 |
| 5 X 25.0 | 196/0.40 | 1.4 | 36 | 2200 |
| 5 X 35.0 | 276/0.40 | 1.4 | 40 | 2925 |
H07RN-F Multicore Type 450/750V EPR/PCP Trailing Rubber Cable
| Core and Size (mm2) | Stranding (Number of Strand / Strand Diameter) | Thickness of Sheath (mm) | Nominal Overall Diameter (mm) | Approx Weight (kg/km) |
| 7 X 1.5 | 30/0.50 | 0.8 | 14.6 | 295 |
| 7 X 2.5 | 50/0.25 | 0.9 | 16.6 | 410 |
| 12 X 1.5 | 30/0.50 | 0.8 | 18.9 | 500 |
| 12 X 2.5 | 50/0.25 | 0.9 | 22 | 720 |
| 19 X 1.5 | 30/0.50 | 0.8 | 22.5 | 715 |
| 19 X 2.5 | 50/0.25 | 0.9 | 26 | 1030 |
| 24 X 1.5 | 30/0.50 | 0.8 | 25 | 900 |
| 24 X 2.5 | 50/0.25 | 0.9 | 29 | 1350 |
| 27 X 1.5 | 30/0.50 | 0.8 | 29 | 1100 |
| 27 X 2.5 | 50/0.25 | 0.9 | 33 | 1521 |
| 37 X 1.5 | 30/0.50 | 0.8 | 29.8 | 1300 |
| 37 X 2.5 | 50/0.25 | 0.9 | 36 | 1900 |
