Silicone Rubber Heating Cable Wires
Jiangyin Senphus Electrical Material Co., Ltd.- Type：Insulated
- Conductor Type：Spiral
- Application：Heating
- Conductor Material：Copper Nickel
- Sheath Material：Silicone Rubber
- Insulation Material：Silicone Rubber
Base Info
- Model NO.：silicone rubber heating wire
- Material Shape：Round Wire
- Range of Application：Heating Resistor
- Certification：ISO9001, CE, UL
- Brand：Senphus
- Transport Package：Roll and Plastic Film and Carton
- Specification：CE
- Trademark：SENPHUS
- Origin：China
- Production Capacity：800000m,Day
Description
length per coil
B, braided silicone rubber heating wire:SH-BSR-20
rated temperature:200ºC
rated voltage:300V
single conductor alloy or resistance wires twist into a spiral on fiberglass
insulation: silicone rubber
reinforced jacket: braided fiberglass layer
UL3323 UL3270 UL3762 UL3859
Except the O.D. of finished product, other parameters are same or similar to those of SH-SR-20.
C, SH-2SR-20
Rated temperature:150ºC-200ºC
Rated volt:300V- 600V
First layer heating conductor: resistance wires twist into a spiral on fiberglass
Second layer heating conductor:alloy wires twist into a spiral on the silicone rubber heating wire
insulation:silicone rubber
UL3780
Similar to thoset of SH-SR-20.
D, two core silicone rubber heating wires:SH-SR2-20
rated temperature:150ºC-200ºC
rated voltage:300V-600V
Twin Conductor: single conductor alloy or resistance wires twist into a spiral on fiberglass
insulation:silicone rubber
the O.D. of this kind of wires is about 4mm. Other parameters are similar to thoset of SH-SR-20.
Our company, Changzhou Shenhui Electrical Material Co., Ltd, produce all kinds of silicon rubber wire/cable on the basis of clients' requirements.
This kind of silicon rubber wire is of resistance wire alloy spirally applied around a glass "Aramid" fiber core. Dia. 2.6mm.
Dia: 1.0mm~6.0mm
Voltage: Under 300V
Power: 0.1~100W/m
Resistance per meter: 0~10000ou/m
Any requirements, please feel free to let us know. You will be satisfied.
