• Model NO.：Concentric Cable
• Certification：ISO, CE, SABS
• Brand：Henan Jiapu
• Voltage Rating：600,1000V
• Standard of Production：IEC60228
• Delivery Length：Accord with The Request
• Min.Order Qty：1km
• Transport Package：Wooden Drum or Wooden&Steel Drum
• Specification：IEC, ASTM, DIN, BS, GB, Any standard
• Trademark：Jiapu
• Origin：Henan China
• HS Code：8544492100
• Production Capacity：2000km,Month

Conductorsolid or stranded plain round copper or aluminum conductor
Shape of Conductor10-16 mm2,round, solid or stranded conductor10-25 mm2,round stranded conductor35-240 mm2, round or sector shaped stranded conductorInsulationPE, XLPE, PVCSheathPE,XLPE,PVC
ASTM 600/1000v
Core
AWG
Structure Size (mm)
Copper cable (kg/km)
Conductor
Insulation
Concentric conductor
Outer sheath
Single wire
XLPE
Single wire
UV-PVC
No.
Dia.
Thick
No.
Dia.
Thick
Dia.
1
16
7
0.49
1.14
39
0.321
1.14
6.82
81.46
1
10
7
0.98
1.14
34
0.511
1.14
8.67
172.04
1
8
7
1.23
1.14
25
0.643
1.14
9.68
221.58
1
6
7
1.55
1.14
25
0.813
1.14
10.98
160.50
1
4
7
1.96
1.14
27
1.020
1.14
12.62
509.26




















IEC 60502-1 IEC 60228 600/1000v
Size (mm2)
Structure Size mm
Copper cable (kg/km)
Concuctor
Insulation
Concentric conductor
Outer sheath
Single wire
Dia.
PVC
Single wire
UV-PVC
No.
Dia.
Thick
No.
Dia.
Thick
Dia.
(kg/km)
10
7
1.35
4.05
1.55
20
0.85
1.4
11.79
301.55
16
7
1.7
5.1
1.55
32
0.85
1.4
12.84
431.7
25
7
2.14
6.42
1.6
29
1.13
1.5
15.02
647.46










16
7
1.7
5.1
1.55
26
1.13
1.4
13.42
244.16
25
7
2.14
6.42
1.6
29
1.13
1.5
15.02
307.3
35
19
1.53
7.65
1.65
27
1.35
1.6
16.99
390.15
