• Model NO.：TFL-DC-1C-2W-00
• Certification：RoHS, UL, CE, ISO9001, CCC
• Brand：Telefly or OEM
• Sheath Material：PVC
• Transport Package：Wooden Reel
• Specification：1000m in length
• Trademark：Telefly or OEM
• Origin：Shenzhen, China
• HS Code：8544700000
• Production Capacity：5000000meter,Month

Basic Info.

Model NO. TFL-DC-1C-2W-00 Certification RoHS, UL, CE, ISO9001, CCC Brand Telefly or OEM Sheath Material PVC Transport Package Wooden Reel Specification 1000m in length Trademark Telefly or OEM Origin Shenzhen, China HS Code 8544700000 Production Capacity 5000000meter/Month

Product Description

Self-supporting Single-mode Outdoor Steel Wire FTTH Optic/Optical Fiber Drop Cable with 1 Core and 3 Steel Wires including 1 Messenger

Description

This optical fiber has one fiber unit positioned in the centre, two parallel steel wires placed at the two sides and a steel wire as the additional strength member called self-supporting messenger. Then the cable is completed with a black PVC sheath.

Characteristics

1.Special low-bend sensitivity fiber provides high bandwidth and excellent communication transmission property;
2.Simple structure, light weight and high practicability;
3.Novel flute design, easily strip and splice, simplify the installation and maintenance;
4.Low smoke, zero halogen and flame retardant sheath.

Technical parameters


Item	Parameter
Cable type	Cable type GJYXFCH-8B6.a2
Cable specification	6.2×2.5
Fiber color	Blue, orange, green, brown, gray, white, red, black
Fiber type	9/125 (G657A2)
Sheath color	Black
Sheath material	PVC
Cable dimension mm	6.2(±0.2)*2.5(±0.2)
Cable weight Kg/km	28.0
Min. bending radius mm	120
Min. bending radius(rip off the messenger wire) mm	10(static) 25(dynamic)
Attenuation dB/km	< 0.4 at 1310nm, <0.3 at 1550nm
Short tension N	600
Short crush N/100mm	2200
Operation temperature °C	-20~+60

Telefly is one of the major fiber optic component suppliers in China (adapters, patch lines, braids, attenuators, shunt media converters, etc.), industrial switches, indoor and outdoor fiber optic equipment for more than 10 years. Our products have been exported to more than 30 countries. I'm honored to work with you for a long-term and win-win cooperation between our two companies.
