UL1571 Single Conductore Electric Wire with Spiral Shield with Power Limited Applications

B&T (Zhangzhou) Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：for General Purpose Internal Wiring of Appliance
  • Conductor Material：Copper
  • Insulation Material：PVC
  • Material Shape：Round Wire

Base Info

  • Model NO.：UL1571
  • Range of Application：Flame Retardant
  • Certification：ISO9001, UL, RoHS, Reach
  • Brand：B&T
  • Rated Temperature：80 ºC
  • Rated Voltage：30V
  • Ref.Standard：UL Subject758, UL1581, C22.2
  • Flame Rating：VW-1
  • Guage：26 AWG
  • Halogen Rating：Hf
  • Core：Single
  • Shield：No
  • Marking：General, OEM
  • Transport Package：610feet in Roll
  • Specification：2pin 20 AWG 2 Conductors
  • Trademark：B&T
  • Origin：Xiamen, Fujian
  • HS Code：8544492100
  • Production Capacity：300, 000km

Description

Maximum Resistance at 20 ºC
Ω/kmAWGNo./mmDia.
mmNom. Thick.
mmNom.Dia.
mm367/0.0500.150.150.451490347/0.0650.1950.150.5908327/0.080.240.230.70597307/0.10.300.300.90354307/0.10.300.200.70354287/0.1270.380.260.90223287/0.1270.380.260.90223267/0.160.480.261.00139247/0.20.60.251.1088.9227/0.160.760.321.4057.52217/0.160.760.251.2557.52026/0.160.940.43108034.61865/0.1271.180.301.7823.31651/0.181.520.322.1515.1
