1kv Yjv Power Cable 70mm Single Core Electrical Cable
Henan Hongda Cable Co., Ltd.- Application：Construction, Underground, Industrial, Power Station, Telecommunication, 1kv Yjv Power Cable 70mm Single Core Electrical Ca
- Voltage：Low and Medium Voltage Cable
- Current：DC & AC
- Insulation Material：XLPE
- Sheath Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：IEC 60502-1
- Wire Core Material：Steel
- Certification：ISO, CCC, CE
- Model：YJV
- Brand：Henan Hongda
- Insulation Color(S)：Natural , Red , Yellow , Blue , Green etc.
- Outer Sheath Color：Black etc.
- No. of Cores：1
- Cross Section：70mm2
- Packing Length：According to Your Request
- Long‐term Working Temperature：90°c
- Max. Temperature in Short Circuit：160°c ,250°c
- Rated Voltage：18,30kv
- Design Standard：IEC 60502-1, IEC 60502-2, IEC 60227, IEC 60228
- Certificate：ISO 14001 , ISO 9001 , Ohasa 18001 , CCC
- Warranty：One Year
- Transport Package：by Sea
- Specification：1kv Yjv power cable 70mm single core electrical ca
- Trademark：HENAN HONGDA
- Origin：China
- HS Code：85444929
- Production Capacity：5000
Description
YJV CU/XLPE/PVC
YJLV
AL/XLPE/PVCmm2 mm mm mm mm kg/km kg/km A A A A 1×4 RE 2.24 0.7 1.4 6.5 73.7 49.0 45 35 60 50 1×6 RE 2.76 0.7 1.4 7.0 95.8 58.7 55 45 70 50 1×10 CC 3.8 0.7 1.4 8.0 140.1 78.2 75 60 95 75 1×16 CC 4.8 0.7 1.4 9.0 201.8 102.8 100 80 125 100 1×25 CC 6.0 0.9 1.4 10.6 298.9 144.2 140 115 160 130 1×35 CC 7.0 0.9 1.4 11.6 396.7 180.2 175 140 190 150 1×50 CC 8.4 1.0 1.4 13.1 543.9 234.6 210 170 225 180 1×70 CC 10.0 1.1 1.4 15.0 744.7 311.6 270 215 280 225 1×95 CC 11.5 1.1 1.5 16.6 985.6 397.8 340 275 335 270 1×120 CC 13.0 1.2 1.5 18.4 1233.0 490.6 400 320 380 305 1×150 CC 14.5 1.4 1.6 20.5 1533.8 605.8 460 370 425 340 1×185 CC 16.2 1.6 1.6 22.7 1884.9 740.3 530 415 480 375 1×240 CC 18.4 1.7 1.7 25.3 2418.0 933.1 625 490 555 435 1×300 CC 20.5 1.8 1.8 27.7 2996.5 1140.4 720 565 630 495 1×400 CC 23.5 2.0 1.9 31.4 3962.3 1487.5 815 640 705 555 1×500 CC 26.5 2.2 2.0 35.0 4933.0 1839.5 855 680 765 595 1×630 CC 30.0 2.4 2.2 39.1 6188.8 2291.0 980 790 860 680
1kv Yjv power cable 70mm single core electrical cable 1kv Yjv power cable 70mm single core electrical cable 1kv Yjv power cable 70mm single core electrical cable
YJLV
AL/XLPE/PVC
1kv Yjv power cable 70mm single core electrical cable 1kv Yjv power cable 70mm single core electrical cable 1kv Yjv power cable 70mm single core electrical cable
