CCTV Cables Security Camera/Antenna TV Rg58 Coaxial Cable Power Wire Camera TV CCTV Signal Coaxial Extension Cable
Hangzhou Spring Electronics Co., Ltd.- Application：Local Communication Cable, Coaxial Cable, LAN Cable, Fiber Optic Cable
- Conductor Material：BC,CCS,CCA,TC,CU,CCAG
- Cover Material：PVC
- Type：Cat 1
- Material Shape：Round Wire
- Conductor Type：Stranded
Base Info
- Model NO.：rg58
- Wire Core Material：Tinned Wire
- Certification：CE, ISO, RoHS
- Model：HYAT-xx
- Applications：CCTV CATV System
- Models：Rg58 Coaxial Cable
- Impendence：50ohm
- Conductor：Tinned Copper
- Braiding：Tinned Copper
- Foam`：Solid
- Coat：PVC
- Transport Package：Packed by Carton,Wooden Drum,Wooden Pallet
- Specification：Local Communication Cable, Coaxial Cable, LAN Cab
- Trademark：FUU
- Origin：Made in China
- HS Code：8544200000
- Production Capacity：24000km,Year
Description
Overview
MIL-C-17 Coaxial Cable TYPE: RG58/U,RG58A/U,RG58C/U Construction Item Material Diameter(mm) Center Conductor Strand Tinned Copper 19/0.18 Dielectric Solid PE 2.95 Overall Braid Tinner Copper Wire Braiding
95% /
Jacket PVC 4.95
Electrical Charateristics Impedance(Ω) 50 Capacitance(pF/m) 101 Velocity of Propagation(%) 66% Inner Conductor DCR(Ω/km) 35.4 Outer Conductor DCR(Ω/km) 13.5 Max Operating Frequency 1000 Operating Temp Range(ºC) (-40 to +85) Attenuation @68°F.(20 ºC ) @Frequency(Mhz) Max Attenuation(dB/100ft) Max Attenuation(dB/100m) 10 1.5 4.9 50 3.3 10.9 100 4.7 15.5 200 7.5 24.5 400 10.6 34.8 600 12.1 39.6 860 17.2 56.4 1000 18.4 60.5
2) Professional Quotation --All prices will be quote according to customers' detailed
specifications & requirements.
3) OEM & ODM Service
4) Can print your own brand on the jacket printing with foot or meter marking.
5) Make customized designs for stickers, drums, outer cartons, etc.
6) Stable Quality --All materials and products passed restrict QC procedures,comply with
international standards.
7) Fast Delivery --LCL orders,15days after confirmation; FCL orders, 20 days after
Confirmation in usual.
