• Model NO.：2X10 mm2
• Material Shape：Round Wire
• Range of Application：Industry
• Certification：ISO9001, CE
• Brand：None
• Transport Package：Carton
• Specification：2X10 mm2
• Trademark：None
• Origin：China
• HS Code：8544492100
• Production Capacity：1000000

Basic Info.

Model NO. 2X10 mm2 Material Shape Round Wire Range of Application Industry Certification ISO9001, CE Brand None Transport Package Carton Specification 2X10 mm2 Trademark None Origin China HS Code 8544492100 Production Capacity 1000000

Product Description

Type MC_Copper Conductor

14 AWG through 1000kcmil Copper THHN/THWN-2 Insulated Singles. UL Listed. 600 Volts. Rated VW-1. Lightweight Aluminum Interlocked Armor.





Scope

This specification covers lightweight aluminum interlock armor type MC cable with soft annealed copper solid or stranded conductor,THHN/THWN insulated singles, conforming to Standard 1569 of Underwriters Laboratories, Inc. UL file No.E313205 .

Application

Type MC cables are suitable for use as follows: branch, feeder and service power distribution in commercial, industrial, institutional, and multi-residential buildings. Power, lighting, control, and signal circuits. Type THHN/THWN conductors are rated 90ºC dry / 75ºC wet. They are permitted for 600V application.

Conductors: Soft annealed copper .

Sizes:14AWG-1000kcmil. .

Insulation: Flame retardant PVC.  Thickness: per UL83.

Color coding:



Conductor jacket: Nylon. Thickness: per UL83.

Cabling: Three or more conductors are assembled without fillers and wraped by a polyester binder tape. A marker tape is inserted under the binder tape.

Armor: Aluminum interlock armor is applied over the assembly.

Jacket: A flame retardant PVC jacket is optional.

Information  on  the  marker tape or the jacket:  AWG or kcmil size,conductor type letters,rated voltage,the name of the manufacturer,UL file number,characteristic,manufacture date,FEET.

Type MC Cable Data1





Type MC Cable Data2



 Packaging Information: Coils or Reel

--  --  --  --  --  --  --  --  --  --  --  --  --  --  --  --  --  --  --



Type MC_Aluminum Conductor

6AWG through 1000kcmil Aluminum cross-linked polyethylene XLPE insulation Insulated XHHW-2 Singles. UL Listed. 600 Volts. Rated VW-1. Lightweight Aluminum Interlocked Armor. PVC jacket





Scope

This specification covers lightweight aluminum interlock armor type MC cable with Compact strand 8000 series aluminum alloy conductors,cross-linked polyethylene XLPE insulation Insulated XHHW-2 Singles, conforming to Standard 1569 of Underwriters Laboratories, Inc. UL file No.E313205 .

Application

Type MC cables Suitable for use in branch, feeder and service power distribution under high ambient temperature in commercial, industrial, institutional, casinos and multi-residential buildings; for power, lighting, control and signal circuits; in concealed or exposed installations; in environmental air-handling spaces per NEC 300.22; in places of assembly per NEC 518.4 and theaters per NEC 520.5; in aerial applications when attached to a messenger; for installation in cable tray and approved raceways; under raised floors for IT equipment per NEC 645.5(D) and 645.5(D)(2); Class I Div 2, Class II Div 2, Class III Div 1 hazardous locations.

Conductors: Compact strand 8000 series aluminum alloy conductors

Sizes:6AWG-1000kcmil.

Insulation: Color coded cross-linked polyethylene XLPE insulation. The cable ground is either bare or has green insulation. Thickness: per UL44.

Color coding:



Cabling: Three or more conductors are assembled without fillers and wraped by a polyester binder tape. A marker tape is inserted under the binder tape.

Armor: Aluminum interlock armor is applied over the assembly.

Jacket: An overall black polyvinyl chloride PVC jacket, which is heat, moisture and sunlight resistant.

Information  on  the  marker tape or the jacket:  AWG or kcmil size, conductor type letters, rated voltage, the name of the manufacturer, UL file number, characteristic, manufacture date, FEET.

--  --  --  --  --  --  --  --  --  --  --  --  --  --  --  --  --  --  --
