High-Power Water-Cooled EV Charging Cable DC Charging Cable

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Battery Industry
  • Conductor Material：Copper
  • Sheath Material：TPU
  • Insulation Material：TPE

Base Info

  • Model NO.：EV Charging Cable
  • Material Shape：Round Wire
  • Range of Application：Battery Industry
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemEV Charging CableConductorCopper wire bareInsulationTPETubeXLPO OR FEPOuter SheathTPUVoltage RatingU0/U: 1000 V Maximum current400A,500A,600ATemperature-40ºC to +105ºCColorOptionalApplicationThe high-power DC charging cable uses liquid cooling technology to cool down, so that the charging cable maintains a low constant temperature during the charging process, and overcomes the thermal damage to the charging gun, charging cable, and charging pile, thereby increasing the charging current. The principle is to add a liquid cooling circulation system inside the cable, and allow the cooling system and the charging system to coexist through the sealed circulation connection inside the connector. The high-power liquid-cooled DC charging cable can fully charge or quickly charge the battery of an electric vehicle in a short time to increase the cruising range, meet customer needs, improve the utilization rate of electric vehicles, and eliminate users' concerns.
