UL2468 Computer Cable TPU Cable PVC Flat Ribbon Cable
B&T (Zhangzhou) Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：for General Purpose Internal Wiring of Appliance
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Model NO.：UL2468
- Material Shape：Flat Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, CE, UL, CCC, RoHS, Reach
- Brand：B&T
- Rated Temperature：80 ºC
- Rated Voltage：300V
- According to：UL Subject758, UL1581, C22.2
- Test：Passes UL VW-1 & CSA FT1 Vertical Flame Test
- Conductor：Stranded, Tinned or Bare Copper Conductor
- Sample：Conventional Sample Free
- Colors：Could Be Customized Color
- Delivery Time：in 7-10days
- Packing：100m,Roll, 305m,Roll, Wrap Plastic Film Packaging
- Service：OEM, ODM
- Transport Package：610feet in Roll
- Specification：2pin 20 AWG 2 Conductors
- Trademark：B&T
- Origin：Xiamen, Fujian
- HS Code：8544492100
- Production Capacity：300, 000km
Description
AWG/NO.OFCONDCond No. Insulation Avg. Thick. Outside Dia. Packing /mm mm mm m/r Ω/mm 30×2C 7/0.1 0.45 1.20×2.50 610 354.33 28×2C 7/0.127 0.45 1.30×2.70 610 223.75 26×2C 7/0.16 0.45 1.40×2.90 610 139.76 24×2C 11/0.16 0.45 1.50×3.10 610 88.36 22×2C 17/0.16 0.45 1.70×3.50 610 60.16 20×2C 21/0.178 0.45 1.90×3.90 305 38.58 18×2C 34/0.178 0.45 2.10×4.30 305 22.98 16×2C 26/0.254 0.45 2.40×4.90 305 15.06
